The Ducati Hypermotard 796 – a bike that embodies the perfect blend of manners and madness. This agile supermotard combines the Italian manufacturer’s signature twin-cylinder power with a lightweight, minimalist design.

At the heart of this machine lies a smooth and flexible four-stroke engine, boasting desmodromic 2 valves per cylinder and SOHC configuration. With its aggressive styling and lower seat height, the Hypermotard 796 is the ultimate urban assault vehicle, capable of tackling daily commutes or spirited open-road excursions with equal ease.

As you settle into the upright seating position, the wide handlebars offer effortless handling through even the most congested city streets. Meanwhile, the bike’s lightweight trellis frame and track-tested chassis geometry provide a rock-solid foundation for thrilling ride dynamics.

The result is an extreme image, paired with an accessible character that defies categorization. With its razor-sharp reflexes and engaging riding experience, the Ducati Hypermotard 796 stands ready to conquer any road, anywhere.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Engine Capacity803 cc / 49 cu in
Max Power59.6 kw / 81 hp
Max Torque75.4 Nm / 7.7 kgm/55.7 lb-ft @ 6250rpm
Fuel Tank Capacity3.3 US gallons / 12.4 L
Seat Height32.5 inches / 825 mm
Ducati Hypermotard 796 (2012)

All Specifications

Make & Model

ModelDucati Hypermotard 796
Year2012

Engine

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Displacement803 cc / 49 cu in
Bore x Stroke88 x 66 mm
Compression Ratio11.0:1
Max Horsepower59.6 kw / 81 hp
Max Torque75.4 Nm / 7.7 kgm/55.7 lb-ft @ 6250rpm
Engine Management SystemSiemens electronic fuel injection, 45mm throttle bodies
Cooling SystemAir cooled
ExhaustLightweight 2-1-2 system with catalytic converter and twin lambda probes.

Performance

Top Speed192.1 km/h / 119.4 mph

Transmission

ClutchAPTC wet multiplate with hydraulic control
Gearbox6 Speed
Gear Ratios1st 32/13 / 2nd 30/18 / 3rd 28/21 / 4th 26/23 / 5th 22/22 / 6th 24/26
Final DriveChain, front sprocket 15, rear sprocket 41

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis frame.
Front SuspensionMarzocchi 43mm USD forks
Front Suspension Travel6.5 inches / 165 mm
Rear SuspensionProgressive linkage with adjustable Sachs monoshock. Aluminium single-sided swingarm
Rear Suspension Travel5.6 inches / 141 mm
Rake24

Wheels & Brakes

Front Tire Size120/70 ZR17
Rear Tire Size180/55 ZR17
Front Brakes2 x 305 mm Semi-floating discs, radially mounted Brembo calipers 4-pistons, 2-pads
Rear BrakesSingle 245 mm disc, 2-piston caliper

Dimension & Weights

Seat Height32.5 inches / 825 mm
Wheelbase57.3 inches / 1455 mm
Fuel Tank Capacity3.3 US gallons / 12.4 L
Dry Weight167 kg / 368 lbs

Features

  • Four stroke engine
  • 90 L twin cylinder engine
  • SOHC design
  • Desmodromic valve actuation
  • 2 valves per cylinder
  • Lower seat height (825mm)
  • Lighter than ever Trellis frame
  • Track-tested chassis geometry
  • Rigidly triangulated frame
  • High fender at the front
  • Dual under-seat silencers at the rear
  • Dry weight of just 167kg (368lb)
  • Lightweight engine
  • 43mm Marzocchi forks for suspension
  • Adjustable spring pre-load and return damping on the rear Sachs suspension unit
  • Radially mounted 4-piston Brembo callipers on the front brakes
  • 305mm semi-floating discs on the front brakes
  • 245mm disc on the rear brakes
  • 2-piston Brembo calliper on the rear brakes
  • Pirelli Diablo Rosso tyres (3.50 front, 5.50 rear)
  • Lightweight aluminium 17″ wheels
  • Improved frame layout with reduced forged elements
