Ducati Hypermotard 1100EVO SP (2010)

Ducati Hypermotard 1100EVO SP (2010)

The Ducati Hypermotard 1100EVO SP is a marvel of engineering, designed to deliver unmatched performance and agility on both the street and the track.

Its heart beats with the Desmodue EVOluzione engine, a masterpiece of Italian design that boasts an impressive 95hp at 7500rpm and 76lb-ft of torque at 5750rpm. This potent powerplant is the result of decades of refinement, featuring advanced technologies such as vacuum-cast crankcases, lightweight rare-earth magnets, and an 848-style Superbike flywheel.

The Hypermotard 1100EVO SP is a machine built for riders who crave edge-of-your-seat excitement, with higher ground clearance, spec suspension, handlebars, and reduced weight all contributing to its exceptional agility. Whether carving up twisties or tackling the Italian Desmo Challenge series, this bike is sure to deliver an unforgettable riding experience that will leave you breathless and begging for more.

Its unique blend of raw power, agile handling, and razor-sharp reflexes makes the Hypermotard 1100EVO SP a true standout in its class, and one that promises to put even the most seasoned riders on their toes.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Engine Capacity1078 cc / 65.8 cu in
Max Power69.9 kw / 95 hp
Max Torque102.9 Nm / 10.5 kgf-m / 76 lb-ft @ 5750 rpm
Fuel Tank Capacity12.4Litres /3.3USgal/ 2.7 Imp gal
Seat Height33.2 inches / 845 mm
Ducati Hypermotard 1100EVO SP (2010)

All Specifications

Make & Model

ModelDucati Hypermotard 1100EVO SP
Year2010

Engine

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Displacement1078 cc / 65.8 cu in
Bore x Stroke98 x 71.5 mm
Compression Ratio10.0:1
Max Horsepower69.9 kw / 95 hp
Max Torque102.9 Nm / 10.5 kgf-m / 76 lb-ft @ 5750 rpm
Engine Management SystemFuel Injection, 45 mm throttle body
Lubrication SystemWet sump
Cooling SystemAir cooled
ExhaustLightweight 2-1-2 system with catalytic converter and lambda probe

Performance

Top Speed220 km/h / 136.7 mph

Transmission

ClutchDrymultiplatewithhydrauliccontrol
Gearbox6 Speed
Gear Ratios1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
Final DriveChain, front sprocket 15, rear sprocket 42

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis
Front Suspension50mm Marzocchi forks, fully adjustable with DLC
Front Suspension Travel7.5 inches / 195 mm
Rear SuspensionProgressive linkage with fully adjustable hlins monoshock. Aluminium single-sided swingarm .
Rear Suspension Travel6.1 inches / 156 mm
Rake24
Trail100 mm / 3.9 in

Wheels & Brakes

Front Wheel/Rim Size5-Spoke in light alloy 3.50 x 17
Front Tire Size120/70ZR17, Pirelli Diablo Rosso
Rear Wheel/Rim Size5-Spoke light alloy 5.50 x 17
Rear Tire Size180/55ZR17, Pirelli Diablo Rosso
Front Brakes2×305 mmSemi-floatingdiscs,radiallymountedBremboMonobloccalipers4-pistons,2-pads
Rear BrakesSingle 245mm disc, 2-piston caliper

Dimension & Weights

Seat Height33.2 inches / 845 mm
Wheelbase57.28 inches / 1455 mm
Fuel Tank Capacity12.4Litres /3.3USgal/ 2.7 Imp gal
Dry Weight172 kg / 379 lbs

Features

  • Four stroke engine
  • 90 L twin cylinder configuration
  • SOHC (Single Overhead Camshaft) design
  • Desmodromic valve actuation system
  • 2 valves per cylinder
  • Higher ground clearance
  • Higher-spec suspension
  • Higher handlebars
  • Reduced weight
  • Lightweight crankcases with Vacural technology
  • Magnesium alternator cover
  • Lighter crankshaft assembly with Superbike flywheel
  • Lightweight rare-earth magnets for generator assembly
  • Improved lubrication and cooling performance from redesigned cylinder head
  • Optimized inlet port shape and combustion chamber design
  • Higher compression ratio
  • Single spark per cylinder ignition system
  • High-flow airbox intake duct
  • Higher-lift valves for maximum volumetric efficiency
