Ducati Hypermotard 1100EVO (2011)

Ducati Hypermotard 1100EVO (2011)

The Ducati Hypermotard 1100EVO: a revolutionary motorcycle that redefines the boundaries of urban riding. With a potent 95hp engine and a dry weight of just 172kg, this bike is the ultimate expression of power and agility.

Its sleek, tapered handlebars transfer razor-sharp control to the rider’s hands, while the full-length seat allows for extreme riding positions with ease. But it’s not just about looks – the EVO has undergone an intense program of redesigns and refinements to deliver improved performance and handling.

At its heart lies a state-of-the-art suspension system, featuring 50mm Marzocchi forks and a fully adjustable ZF Sachs shock, all working in harmony with a rigidly triangulated Trellis frame. The result is a bike that accelerates with thrilling ferocity and brakes with unflappable confidence.

And what of the engine? It’s the perfect blend of torquey power delivery and exhilarating excitement, making it the ultimate companion for any riding experience. The Desmodue 1100 EVOluzione – a name that says it all.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Engine Capacity1078 cc / 65.8 cu in
Max Power69.9 kw / 95 hp
Max Torque102.9 Nm / 10.5 kgf-m / 76 lb-ft @ 5750 rpm
Fuel Tank Capacity12.4Litres /3.3USgal/ 2.7 Imp gal
Seat Height33.2 inches / 845 mm
Ducati Hypermotard 1100EVO (2011)

All Specifications

Make & Model

ModelDucati Hypermotard 1100EVO
Year2011

Engine

Engine TypeFour stroke, 90 L twin cylinder, SOHC, desmodromic 2 valves per cylinder
Displacement1078 cc / 65.8 cu in
Bore x Stroke98 x 71.5 mm
Compression Ratio10.0:1
Max Horsepower69.9 kw / 95 hp
Max Torque102.9 Nm / 10.5 kgf-m / 76 lb-ft @ 5750 rpm
Engine Management SystemFuel Injection, 45 mm throttle body
Lubrication SystemWet sump
Cooling SystemAir cooled
ExhaustLightweight 2-1-2 system with catalytic converter and lambda probe

Performance

Top Speed220 km/h / 136.7 mph

Transmission

ClutchDrymultiplatewithhydrauliccontrol
Gearbox6 Speed
Gear Ratios1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
Final DriveChain, front sprocket 15, rear sprocket 42

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis
Front Suspension50mm Marzocchi forks, fully adjustable
Front Suspension Travel6.5 inches / 165 mm
Rear SuspensionProgressive linkage with fully adjustable ZF Sachs monoshock. Aluminium single-sided swingarm
Rear Suspension Travel5.6 inches / 141 mm
Rake24
Trail100 mm / 3.9 in

Wheels & Brakes

Front Wheel/Rim Size5-Spoke in light alloy 3.50 x 17
Front Tire Size120/70ZR17, Pirelli Diablo Rosso
Rear Wheel/Rim Size5-Spoke light alloy 5.50 x 17
Rear Tire Size180/55ZR17, Pirelli Diablo Rosso
Front Brakes2×305 mmSemi-floatingdiscs,radiallymountedBremboMonobloccalipers4-pistons,2-pads
Rear BrakesSingle 245mm disc, 2-piston caliper

Dimension & Weights

Seat Height33.2 inches / 845 mm
Wheelbase57.28 inches / 1455 mm
Fuel Tank Capacity12.4Litres /3.3USgal/ 2.7 Imp gal
Dry Weight172 kg / 379 lbs

Features

  • Four-stroke, 90 L twin cylinder engine
  • SOHC design
  • Desmodromic valve actuation system with 2 valves per cylinder
  • 1100cc displacement
  • 98×71.5mm bore and stroke
  • 95hp (69.9kW) @ 7500rpm power output
  • 76lb-ft (10.5kgm) of torque @ 5750rpm
  • Vacuum cast crankcases using Vacural technology
  • Lightweight crankshaft assembly with 848 Superbike flywheel
  • Magnesium alternator cover
  • Rare-earth magnets for generator assembly
  • Dry weight of 172kg (379lb)
  • Improved frame layout with reduced forged elements
  • Rigidly triangulated Trellis frame
  • Track-tested chassis geometry
  • 50mm Marzocchi forks with high rigidity stainless steel sliders and external adjustability
  • Fully adjustable ZF Sachs rear shock with single-sided swingarm
  • Lightweight wheels on large diameter axles with Pirelli Diablo Rosso tyres
  • Radially mounted Brembo 4-piston callipers on 305mm twin discs up front, and a 245mm disc at the rear
