Ducati DiavelCarbon (2014)

Ducati DiavelCarbon (2014)

The Ducati DiavelCarbon (2014) embodies the perfect fusion of style and performance, where Italian engineering meets cutting-edge design. At its heart lies the 1,198cc L-Twin Testastretta engine, delivering an explosive 162 horsepower and 95 lb-ft of torque, propelling the bike from 0-60mph in just 3 seconds.

A lightweight 2-1-2 exhaust system, complete with twin aluminium mufflers and hydraulic clutch control, works in harmony to optimize power delivery. Meanwhile, the progressive linkage monoshock suspension and Marzocchi forks with diamond-like coating ensure a smooth ride and razor-sharp handling.

With its stunning red carbon finish, black accessories, and milled aluminium components, the DiavelCarbon exudes an air of sophistication and high-performance capability. But it’s not just about looks – this bike is designed to deliver an exhilarating riding experience that’s nothing short of addictive. It accelerates faster, stops sooner, and changes direction with even more agility than its predecessor, thanks in part to a 2.5kg weight saving achieved through the use of beautifully forged Marchesini wheels.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity1198.4 cc / 73.1 cu in
Max Power119 kw / 162 hp
Max Torque127.5 Nm / 13.0 kgf-m /94 lb-ft / @ 8000rpm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Seat Height30.3 inches / 770 mm
Ducati DiavelCarbon (2014)

All Specifications

Make & Model

ModelDucati DiavelCarbon
Year2014

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement1198.4 cc / 73.1 cu in
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower119 kw / 162 hp
Max Torque127.5 Nm / 13.0 kgf-m /94 lb-ft / @ 8000rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies with RbW
Cooling SystemLiquid cooled
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers

Performance

Top Speed252.4 km/h / 156.8 mph

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Final DriveChain Front sprocket 15; Rear sprocket 43

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis frame
Front SuspensionMarzocchi 50mm fully adjustable USD forks
Front Suspension Travel4.72 inches / 120 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm,
Rear Suspension Travel4.72 inches / 120 mm
Rake28

Wheels & Brakes

Front Tire Size120/70 ZR 17
Rear Tire Size240/45 ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS
Rear BrakesSingle265 mm disc, 2-piston floating caliper with ABS

Dimension & Weights

Seat Height30.3 inches / 770 mm
Wheelbase62.6 inches / 1590 mm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Dry Weight205 Kg / 452 lbs

Features

  • Lightweight 2-1-2 system with catalytic converter and two lambda probes
  • Twin aluminium mufflers
  • Light action, wet, multiplate clutch with hydraulic control
  • Self-servo action on drive, slipper action on over-run
  • Progressive linkage with fully adjustable Sachs monoshock
  • Aluminium single-sided swingarm
  • Machine finished forged aluminium Marchesini wheels
  • Marzocchi forks with diamond-like coating (DLC)
  • Brake disc carriers in milled aluminium
  • Carbon fibre fairing and black accessories
  • Reduced weight of 205 kg due to lightweight composites and milled aluminium components
  • Exclusive red carbon paint job with red frame
  • Black wheels turned and milled to expose natural aluminium below
  • Carbon fibre used for tank panels, single-seat cover, and front mudguard to reduce weight
  • Low friction diamond-like carbon finish on Marzocchi fork sliders
  • Forged, lightweight Marchesini wheels saving 5.5lb (2.5kg) of unsprung weight
