Ducati Diavel Carbon (2017 – 2018)

Ducati Diavel Carbon (2017 - 2018)

The 2017-2018 Ducati Diavel Carbon embodies the perfect blend of power, style, and innovation. Its L-twin engine delivers an intense riding experience, with its distinctive soundtrack and instant throttle response igniting a passion for motorcycling in every rider.

Forged Marchesini wheels and sleek Zircotec-coated exhaust pipes add to the motorcycle’s commanding presence, while the massive 240 section rear tyre communicates power and style. Despite its intimidating stance, the Diavel handles with precision thanks to its advanced suspension and braking system.

The Ducati Diavel Carbon is a testament to the brand’s commitment to performance redefined, pushing the boundaries of what a motorcycle can be. With its sophisticated carbon fibre details and premium componentry, this bike is not just a machine – it’s an extension of the rider’s personality.

Key Specifications

Engine TypeFour stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power152 hp / 113.3 kW @ 9500rpm
Max Torque94 lb-ft / 127.5 Nm @ 8000rpm
Fuel Tank Capacity5.3 US gallons / 17.0 L
Weight (Wet/Kerb)527 lbs / 239 kg
Seat Height30.3 inches / 770 mm
Ducati Diavel Carbon (2017 - 2018)

All Specifications

Make & Model

ModelDucati Diavel Carbon
Year2017 – 2018

Engine

Engine TypeFour stroke, 90°“L”twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9mm
Compression Ratio11.5:1
Max Horsepower152 hp / 113.3 kW @ 9500rpm
Max Torque94 lb-ft / 127.5 Nm @ 8000rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies with RbW
Cooling SystemLiquid cooled,
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers

Performance

Top Speedn/a

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Final DriveChain Front sprocket 15; Rear sprocket 43

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis frame
Front SuspensionMarzocchi 50mm fully adjustable USD forks,
Front Suspension Travel4.72 inches / 120 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm,
Rear Suspension Travel4.72 inches / 120 mm
Rake28°
Trail70°

Wheels & Brakes

Front Tire Size120/70 ZR 17
Rear Tire Size240/45 ZR17
Front Brakes2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS
Rear BrakesSingle265mm disc, 2-piston floating calliper with ABS

Dimension & Weights

Seat Height30.3 inches / 770 mm
Wheelbase62.6 inches / 1590 mm
Fuel Tank Capacity5.3 US gallons / 17.0 L
Wet (kerb/curb) Weight527 lbs / 239 kg
Dry Weight210 Kg / 463 lbs

Features

  • Four stroke, 90°“L”twin cylinder engine
  • DOHC, desmodromic 4 valve per cylinder design
  • Mitsubishi electronic fuel injection system
  • Mikuni elliptical throttle bodies with RbW
  • Lightweight 2-1-2 exhaust system with catalytic converter and lambda probes
  • Twin aluminium mufflers
  • Light action, wet, multiplate clutch with hydraulic control
  • Self-servo action on drive, slipper action on over-run
  • Six-speed transmission (37/15, 30/17, 27/20, 24/22, 23/24, 22/25)
  • Progressive linkage with fully adjustable Sachs monoshock
  • Aluminium single-sided swingarm
  • Dual 320mm semi-floating discs with radially mounted Brembo callipers and ABS
  • Single 265mm disc with floating calliper and ABS
  • Length: 2235 mm / 87.9 in
  • Width: 860 mm / 33.8 in
  • Height: 1192 mm / 46.9 in
Ducati Diavel Carbon (2017 - 2018)
Ducati Diavel Carbon (2017 - 2018)
Ducati Diavel Carbon (2017 - 2018)
