Ducati Diavel AMG Special Edition (2012)

Ducati Diavel AMG Special Edition (2012)

The 2012 Ducati Diavel AMG Special Edition is a testament to the union of Italian style and German engineering precision. This flagship model boasts a 1198cc Testastretta engine, delivering a unique blend of power and character that sets it apart from other motorcycles.

Its 2-1-2 exhaust system, complete with twin aluminium mufflers and self-servo action on drive, ensures an exhilarating riding experience. The Ducati Diavel AMG Special Edition’s handling is further enhanced by its lightweight aluminium single-sided swingarm and fully adjustable Sachs monoshock suspension.

This limited-edition motorcycle represents a true masterpiece of co-creation between Ducati and Mercedes-AMG, combining the best of both worlds in terms of design, performance, and exclusivity. With only a select few models available, this is a rare opportunity for discerning riders to own a piece of history.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power119 kw / 162 hp
Max Torque127.5 Nm / 13.0 kgf-m /94 lb-ft / @ 8000rpm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Weight (Wet/Kerb)527 lbs / 239 kg
Seat Height30.3 inches / 770 mm
Ducati Diavel AMG Special Edition (2012)

All Specifications

Make & Model

ModelDucati Diavel AMG Special Edition
Year2012

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower119 kw / 162 hp
Max Torque127.5 Nm / 13.0 kgf-m /94 lb-ft / @ 8000rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies with RbW
Cooling SystemLiquid cooled
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers

Performance

Top Speed252.4 km/h / 156.8 mph

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Final DriveChain Front sprocket 15; Rear sprocket 43

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis frame
Front SuspensionMarzocchi 50mm fully adjustable USD forks
Front Suspension Travel4.72 inches / 120 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm,
Rear Suspension Travel4.72 inches / 120 mm
Rake28

Wheels & Brakes

Front Tire Size120/70 ZR 17
Rear Tire Size240/45 ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS
Rear BrakesSingle265 mm disc, 2-piston floating caliper with ABS

Dimension & Weights

Seat Height30.3 inches / 770 mm
Wheelbase62.6 inches / 1590 mm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Wet (kerb/curb) Weight527 lbs / 239 kg
Dry Weight210 Kg / 463 lbs

Features

  • Lightweight 2-1-2 system with catalytic converter and two lambda probes
  • Twin aluminium mufflers
  • Light action, wet, multiplate clutch with hydraulic control
  • Self-servo action on drive, slipper action on over-run
  • Progressive linkage with fully adjustable Sachs monoshock
  • Aluminium single-sided swingarm
  • 5.2 L/100 km fuel efficiency
  • Ducati and Mercedes AMG collaboration
  • Exclusive styling features from both brands
  • 5-spoke wheel styling
  • Carbon fibre lateral radiator grills with aluminium trim
  • AMG-style sport exhaust system with engraved end-caps
  • AMG-style horizontally ribbed seat upholstered in Alcantara
  • Hand-set Desmodromic cam-timing
  • Engine technician’s name engraved on engine casing
  • Numbered plaque on fuel tank
  • Matte black carbon fibre bodywork
  • Diamond White Bright stripe and frame colour
  • Black wheels
  • AMG branded special edition wheels, seat, and exhaust end-caps
Ducati Diavel AMG Special Edition (2012)
Ducati Diavel AMG Special Edition (2012)
Ducati Diavel AMG Special Edition (2012)
Ducati Diavel AMG Special Edition (2012)
