Ducati Diavel (2017 – 2018)

Ducati Diavel (2017 - 2018)

The Ducati Diavel is a masterclass in engineering and design, boasting an intoxicating blend of power and style that will leave even the most seasoned riders weak-kneed. At its heart lies a potent 1103cc “L” twin cylinder engine, its DOHC layout and desmodromic valves delivering an unparalleled level of performance and character.

The Diavel’s riding experience is as captivating as it is intimidating. With its muscular physique and aggressive stance, the bike is an unapologetic statement piece that demands attention on the road. The addition of lateral radiators only serves to amplify this effect, imbuing the Diavel with a formidable presence that’s impossible to ignore.

The marriage of this potent engine with Ducati’s renowned handling prowess creates a truly unforgettable riding experience. With its exceptional power delivery and razor-sharp reflexes, the Diavel is an absolute joy to ride, delivering an unparalleled level of excitement and adrenaline-fueled thrills at every twist and turn.

Key Specifications

Engine TypeFour stroke, 90° “L” twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Engine Capacity73.1 cubic inches / 1198.4 cc
Max Power152 hp / 113.3 kW @ 9500rpm
Max Torque94 lb-ft / 127.5 Nm @ 8000rpm
Fuel Tank Capacity5.3 US gallons / 17.0 L
Weight (Wet/Kerb)527 lbs / 239 kg
Seat Height30.3 inches / 770 mm
Ducati Diavel (2017 - 2018)

All Specifications

Make & Model

ModelDucati Diavel
Year2017 – 2018

Engine

Engine TypeFour stroke, 90° “L” twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Displacement73.1 cubic inches / 1198.4 cc
Bore x Stroke106 x 67.9mm
Compression Ratio11.5:1
Max Horsepower152 hp / 113.3 kW @ 9500rpm
Max Torque94 lb-ft / 127.5 Nm @ 8000rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies with RbW
Cooling SystemLiquid cooled
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers

Performance

Top Speedn/a

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Final DriveChain Front sprocket 15; Rear sprocket 43

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis frame
Front SuspensionMarzocchi 50mm fully adjustable USD forks,
Front Suspension Travel4.72 inches / 120 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm,
Rear Suspension Travel4.72 inches / 120 mm
Rake28°
Trail70°

Wheels & Brakes

Front Tire Size120/70 ZR 17
Rear Tire Size240/45 ZR17
Front Brakes2 x 320mm semi-floating discs, radially mounted Monobloc Brembo callipers, 4-piston with ABS
Rear BrakesSingle265mm disc, 2-piston floating calliper with ABS

Dimension & Weights

Seat Height30.3 inches / 770 mm
Wheelbase62.6 inches / 1590 mm
Fuel Tank Capacity5.3 US gallons / 17.0 L
Wet (kerb/curb) Weight527 lbs / 239 kg
Dry Weight210 Kg / 463 lbs

Features

  • Four stroke, 90° “L” twin cylinder engine
  • Desmodromic 4 valve per cylinder
  • Mitsubishi electronic fuel injection system
  • Mikuni elliptical throttle bodies with RbW Lightweight 2-1-2 system
  • Catalytic converter and two lambda probes
  • Twin aluminium mufflers
  • Light action, wet, multiplate clutch with hydraulic control
  • Self-servo action on drive, slipper action on over-run
  • 6-speed gearbox
  • Progressive linkage with fully adjustable Sachs monoshock
  • Aluminium single-sided swingarm
  • Radially mounted Monobloc Brembo callipers
  • ABS system with dual 320mm discs at front
  • Single 265mm disc with 2-piston floating calliper at rear
  • Length: 2235 mm / 87.9 in
  • Width: 860 mm / 33.8 in
  • Height: 1192 mm / 46.9 in
