The Ducati Diavel is a masterclass in contrasts: a lightweight, yet powerful package that defies categorization. Its 162 horsepower is delivered with precision via the three Riding Modes, while its sleek design and sophisticated features make it a head-turner on any road.

A key highlight of the Diavel’s engineering is its state-of-the-art exhaust system, boasting a lightweight 2-1-2 setup with catalytic converter and twin lambda probes. Meanwhile, its clutch and suspension systems showcase Ducati’s attention to detail, offering light action and precise control.

But it’s on the road where the Diavel truly comes alive. With a manageable weight of just 463 pounds and an impressive 45.6 US mpg fuel economy, this bike is as much at home on a long highway cruise as it is carving through twisties.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity1198.4 cc / 73.1 cu in
Max Power119 kw / 162 hp
Max Torque127.5 Nm / 13.0 kgf-m /94 lb-ft / @ 8000rpm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Weight (Wet/Kerb)527 lbs / 239 kg
Seat Height30.3 inches / 770 mm
Ducati Diavel (2014)

All Specifications

Make & Model

ModelDucati Diavel
Year2014

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement1198.4 cc / 73.1 cu in
Bore x Stroke106 x 67.9 mm
Compression Ratio11.5:1
Max Horsepower119 kw / 162 hp
Max Torque127.5 Nm / 13.0 kgf-m /94 lb-ft / @ 8000rpm
Engine Management SystemMitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies with RbW
Cooling SystemLiquid cooled
ExhaustLightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers

Performance

Top Speed252.4 km/h / 156.8 mph

Transmission

ClutchLight action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run.
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 27/20 / 4th24/22 / 5th 23/24 / 6th 22/25
Final DriveChain Front sprocket 15; Rear sprocket 43

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel Trellis frame
Front SuspensionMarzocchi 50mm fully adjustable USD forks
Front Suspension Travel4.72 inches / 120 mm
Rear SuspensionProgressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm,
Rear Suspension Travel4.72 inches / 120 mm
Rake28

Wheels & Brakes

Front Tire Size120/70 ZR 17
Rear Tire Size240/45 ZR17
Front Brakes2 x 320 mm Semi-floating discs, radially mounted Monobloc Brembo calipers, 4-piston with ABS
Rear BrakesSingle265 mm disc, 2-piston floating caliper with ABS

Dimension & Weights

Seat Height30.3 inches / 770 mm
Wheelbase62.6 inches / 1590 mm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Wet (kerb/curb) Weight527 lbs / 239 kg
Dry Weight210 Kg / 463 lbs

Features

  • Lightweight 2-1-2 system with catalytic converter and two lambda probes
  • Twin aluminium mufflers
  • Light action, wet, multiplate clutch with hydraulic control
  • Self-servo action on drive, slipper action on over-run
  • Progressive linkage with fully adjustable Sachs monoshock
  • Aluminium single-sided swingarm
  • 5.2 L/100 km fuel efficiency
  • Weighs 463 lb
  • 162 hp engine
  • Three Riding Modes
  • Tank-side air-ducts in natural aluminium and carbon fibre radiator panels
  • Vintage-style, horizontally-ribbed seat upholstery
  • DLC-coated black fork sliders (on Diavel Dark)
  • Black-anodised tank-side air-ducts (on Diavel Dark)
  • Black-finished silencers (on Diavel Dark)
  • Black-finished foot control pedals and bars (on Diavel Dark)
  • Black-finished mirrors and headlamp body (on Diavel Dark)
  • Racing black frame (on Diavel Strada)
  • Black wheels with subtle black textured finish (on Diavel Strada)
