Ducati 999R (2003)

Ducati 999R (2003)

The Ducati 999R is a limited-edition powerhouse that embodies the perfect marriage of technology and performance.

Its high-performance Testastretta engine pumps out an astonishing 139 horsepower at 10,000 RPM, coupled with 11 kgm of torque at 8,000 RPM. The engine’s advanced design and short-stroke configuration allow for exceptional responsiveness and handling on the track.

The chassis itself is a masterpiece of engineering, featuring a progressive linkage with fully adjustable Öhlins monoshock suspension. The rear shock absorber and fork are also by Öhlins, with preload, rebound, and compression damping all adjustable to suit the rider’s preference.

The Brembo Marchesini wheels are forged from high-strength aluminum alloy, resulting in a wheel that is both incredibly rigid and remarkably lightweight. And with the inclusion of a Termignoni 102 Db exhaust system, specifically designed for track use only, this bike is truly built for speed.

In short, the Ducati 999R is an unapologetic beast of a motorcycle, designed to dominate the track and leave all else in its dust.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Engine Capacity999 cc / 70 cu in
Max Power101 kw / 139 hp
Max Torque108Nm / 11.0 kgf-m / 79.7 ft-lb @ 8000 rpm
Fuel Tank Capacity4.1 US gallons / 15.5 L
Seat Height30.7 inches / 780 mm
Ducati 999R (2003)

All Specifications

Make & Model

ModelDucati 999R
Year2003

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Displacement999 cc / 70 cu in
Bore x Stroke104 x 58.8 mm
Compression Ratio12.3:1
Max Horsepower101 kw / 139 hp
Max Torque108Nm / 11.0 kgf-m / 79.7 ft-lb @ 8000 rpm
Engine Management SystemWeber Marelli electronic fuel injection, 54 mm throttle body
Lubrication SystemWet sump
Cooling SystemLiquid cooled
ExhaustSingle steel muffler with catalytic converter

Performance

Top Speed280 km/h / 174 mph

Transmission

ClutchDry multiplate with hydraulic control
Gearbox6 Speed
Primary Drive RatioStraight cut gears, 1.84:1
Gear Ratios1st 2.466 / 2nd 1.765 / 3rd 1.400 / 4th 1.182 / 5th 1.043 / 6th 0.958:1
Final DriveChain

Electrical & Electronics System

Battery12V 10Ah
StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis
Front Suspensionhlins43mm upside-down fully adjustable fork with TiN surface treatment
Front Suspension Travel4.7 inches / 120 mm
Rear SuspensionProgressive linkage with fully adjustablehlinsmonoshock
Rear Suspension Travel5 inches / 128 mm
Rake23.5 – 24.5
Trail97 mm / 3.8 in

Wheels & Brakes

Front Wheel/Rim SizeY-shaped 5-spoke light alloy 3.50 x 17
Front Tire Size120/70 ZR17
Rear Wheel/Rim SizeY-shaped 5-spoke light alloy 5.50 x 17
Rear Tire Size190/50 ZR17
Front Brakes2 x 320 mm Discs, 4 piston calipers
Rear BrakesSingle 245mm disc, 2 piston caliper

Dimension & Weights

Overall Width730 mm / 28.7 in Height 1110 mm / 43.7 in
Seat Height30.7 inches / 780 mm
Wheelbase55.9 inches / 1420 mm
Fuel Tank Capacity4.1 US gallons / 15.5 L
Dry Weight193 kg / 439 lbs

Features

  • High performance big bore/short stroke Testastretta engine
  • 139 Hp at 10,000 RPM
  • 11 kgm of torque at 8,000 RPM
  • Progressive linkage with fully adjustable hlins monoshock
  • Rear shock absorber and fork are by hlins, adjustable for pre-load, rebound, and compression damping
  • 43 millimetre diameter fork stanchions with titanium-nitride treatment
  • Special front fork lowers allow mounting of radial callipers
  • Brembo Marchesini wheels made from forged aluminium alloy
  • Wheel has higher torsional rigidity and lower weight
  • Termignoni 102 Db exhaust with horizontal rear half-manifold without catalytic converter
  • Dedicated electronic control unit reduces weight by three kilos (6.6 lbs)
  • Carbon fibre fairing, seat unit, front mudguard, cam belt covers, and exhaust
  • Magnesium cam covers
  • Marchesini wheels
  • Top-line Ohlins suspension and steering damper
  • Brembo radial brakes
