The 2016 Ducati 959 Panigale is poised to revolutionize the Supermid segment with its innovative blend of style and performance.
This potent machine boasts a new 955 cm3 twin-cylinder engine, dubbed the “Superquadro,” which delivers an impressive 157 hp at 10,500 rpm. With a focus on delivering more enjoyable everyday riding experiences and thrilling track sessions alike, the Ducati engineers have optimized the torque curve for a smoother power delivery.
With its dry weight of only 176 kg, the 959 Panigale achieves an outstanding power-to-weight ratio, ensuring exceptional response and agility while maintaining full compliance with Euro 4 standards. Every aspect of this bike, from its unmistakable silhouette to its cutting-edge technology package, proudly wears its Ducati heritage on its sleeve.
The culmination of these impressive design and engineering decisions results in a truly exceptional motorcycle experience that will undoubtedly leave riders eagerly anticipating their next adventure – the 2016 Ducati 959 Panigale is ready to take your riding experience to new heights.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity
955 cc / 58.3 cu in
Max Power
117.1 kw / 157 hp
Max Torque
107.4 Nm / 10.9 kgf-m / 79 lb-ft @ 9000 rpm
Fuel Tank Capacity
4.5 US gallons / 17.0 L
Weight (Wet/Kerb)
440 lbs / 200 kg
Seat Height
32.4 inches / 825 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati 959 Panigale
Year
2016
Engine
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement
955 cc / 58.3 cu in
Bore x Stroke
100 x 60.8 mm
Compression Ratio
12.5:1
Max Horsepower
117.1 kw / 157 hp
Max Torque
107.4 Nm / 10.9 kgf-m / 79 lb-ft @ 9000 rpm
Engine Management System
Oval throttle bodies with two injectors per cylinder, 41.8 mm intake valve and 34 mm foutlet valve
Cooling System
Liquid cooled
Exhaust
Redesigned exhaust system with twin silencers placed on the right-hand side of the bike
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Oil bath, progressive self-servo mechanism that compresses the friction plates
Gearbox
6-Speed
Final Drive
Chain, 15/43 ratio
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Superquadro engine as a stressed member of the chassis and a compact, enhanced-strength, die-cast aluminium monocoque
Front Suspension
43 mm Showa BPF forks, fully adjustable in spring pre-load and compression and rebound damping
Front Suspension Travel
4.72 inches / 120 mm
Rear Suspension
Fully adjustable, side-mounted Sachs monoshock
Rear Suspension Travel
5.12 inches / 130 mm
Rake
24º
Trail
96 mm / 3.8 in
Wheels & Brakes
Front Wheel/Rim Size
10 Spoke, 3.50 x 17 in
Front Tire Size
120/70 ZR17, Pirelli Diablo Rosso Corsa
Rear Wheel/Rim Size
10 Spoke, 5.00 x 17 in
Rear Tire Size
180/60 ZR17, Pirelli Diablo Rosso Corsa
Front Brakes
2x 320 mm discs, twin radially-mounted M4.32 Brembo monobloc calipers actuated by master cylinders, ABS
Rear Brakes
Single 245 mm disc, single Brembo caliper, ABS
Dimension & Weights
Seat Height
32.4 inches / 825 mm
Wheelbase
56.3 inches / 1431 mm
Fuel Tank Capacity
4.5 US gallons / 17.0 L
Wet (kerb/curb) Weight
440 lbs / 200 kg
Dry Weight
176 kg / 387 lbs
Features
955 cm3 twin-cylinder engine
Euro 4 type-approval
157 hp maximum power at 10,500 rpm
107.4 Nm torque at 9,000 rpm
Super-smooth engine
Stressed member of the monocoque frame
Dry weight: 176 kg
Riding Mode technology including Ride-by-Wire
Ducati Quick Shift (DQS)
Bosch ABS with three-stage control
Ducati Traction Control (DTC)
Engine Brake Control (EBC)
Servoassisted slipper function clutch
Aluminium billet-machined footrests
Redesigned nose fairing, headlight, and tailpiece
New rear view mirrors
Wider nose fairing and screen for improved aerodynamics
Larger-section front air intakes
Ducati Safety Pack (ABS, DTC)
Three Riding Modes: Race, Sport, Wet
