Ducati 916 SP / SP2 / SP3 (1994 – 96)

Ducati 916 SP / SP2 / SP3 (1994 - 96)

The Ducati 916 SP / SP2 / SP3 – a testament to Italian ingenuity and precision engineering. This stripped-down, high-performance variant boasts an exceptional Four-stroke, 90° L-twin cylinder engine with DOHC and desmodromic 4-valve per cylinder configuration.

Riding the 916 SP is an exhilarating experience, thanks to its responsive engine character that delivers instant power and agility. The bike’s handling is further enhanced by the lightweight frame, combined with high-performance components such as full-floating cast iron brake rotors and an Ohlins rear shock.

The subtle yet effective use of carbon fibre parts and a Monoposto tail gives the 916 SP an unmistakable air of sportiness. With its unique engine internals, including reinforced main bearings and a specially designed clutch pack, this bike is a masterclass in performance refinement.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven
Engine Capacity916 cc / 55.9 cu in
Max Power96.4 kw / 131 hp
Max Torque73 ft-lb / 99 nm
Fuel Tank Capacity4.4 US gallons / 17.0 L
Seat Height31.1 inches / 790 mm
Ducati 916 SP / SP2 / SP3 (1994 - 96)

All Specifications

Make & Model

ModelDucati 916 SP / SP2 / SP3
Year1994 – 96

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven
Displacement916 cc / 55.9 cu in
Bore x Stroke94 x 66 mm
Compression Ratio11.2:1
Max Horsepower96.4 kw / 131 hp
Max Torque73 ft-lb / 99 nm
Engine Management SystemWeber I.A.W. CPU P8 electronic indirect injection
Lubrication SystemWet sump
Cooling SystemLiquid cooled

Performance

Top Speed269.3 km/h / 167.3 mph

Transmission

ClutchDry, multiplate
Gearbox6 Speed
Primary Drive Ratio2:1 (31/62)
Gear Ratios1st 2.466 / 2nd 1.765 / 3rd 1.350 / 4th 1.091 / 5th 0.958 / 6th 0.857
Final DriveChain

Electrical & Electronics System

Battery12V 16Ah
StarterElectric

Chassis & Suspension

Frame TypeSteel, Trellis frame
Front Suspension43 mm Adjustable Showa GD051 inverted fork
Front Suspension Travel5.0 inches / 127 mm
Rear Suspensionhlins DU 3420 progressive cantilever linkage with adjustable monoshock
Rear Suspension Travel5.1 inches / 130 mm
RakeAdjustable 24o- 25o
Trail94 – 100 mm / 3.7 – 3.9 in

Wheels & Brakes

Front Wheel/Rim Size3.50 x 17
Front Tire Size120/70 ZR17
Rear Tire Size190/50 ZR17 or 180/55 ZR17
Front Brakes2 x 320 mm Discs, 4 piston calipers
Rear BrakesSingle 220 disc, 2 piston caliper

Dimension & Weights

Seat Height31.1 inches / 790 mm
Wheelbase56.6 inches / 1410 mm
Fuel Tank Capacity4.4 US gallons / 17.0 L
Dry Weight192 kg / 423 lbs

Features

  • Four-stroke, 90 L twin cylinder engine
  • DOHC, desmodromic 4 valve per cylinder
  • Belt driven engine
  • Carbon fibre parts on the frame and bodywork
  • Monoposto tail with a white numberplate paint scheme
  • Full floating cast iron brake rotors
  • Ohlins rear shock
  • Carbon fibre airbox (optional)
  • Unique crankcases with rough cast texture
  • Reinforced main bearings
  • Cylinder heads based on 916 Racing heads
  • Unique clutch pack
  • Final drive lowered with a 14 tooth front sprocket
  • High flow oil pump and forced lubrication to gudgeon pins
  • Pankl titanium H-section con rods
  • Lightened crankshaft counterweights
  • New pistons with increased compression ratio
  • Enlarged valves (34/30mm)
  • Ported cylinder heads from the factory
  • G/A cams
  • Fuel injection throttle bodies with two injectors per cylinder and a P8 ECU
  • High-pressure fuel regulator
  • Unique exhaust headers and half system
