The Ducati 916 – a fusion of style and speed that left an indelible mark on the motorcycle world. This Italian V-twin’s breathtaking beauty, combined with its thunderous engine performance and sublime handling, made it an instant hit when launched in 1994.

As a development of the liquid-cooled, eight-valve desmodromic V-twin line, which stretches back to the iconic 851 of 1988, the 916’s design was inspired by designer Massimo Tamburini. The fairing’s sharp nose and aggressive twin headlights are matched by elegant scarlet shapes in the fuel tank and fairing, while the rear end is equally dramatic with its diminutive tailpiece, high-level silencers, and single-sided swingarm.

Underneath its stunning skin lies a bored-out version of the 888 model’s engine, now displacing 916cc. A revised Weber fuel-injection system and larger curved radiator combine to raise peak output by a few horsepower to 114bhp at 9000rpm. In the hands, the 916 delivers an exhilarating riding experience, with its chassis design combining traditional steel ladder frame with a tubular aluminium rear subframe.

The result is a bike that not only looks like a work of art but also feels like one – handling corners with precision and poise, while unleashing its fury on the straights. The Ducati 916 is truly a masterpiece that will leave you breathless and begging for more.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven
Engine Capacity916 cc / 55.9 cu in
Max Power83.8 kw / 114 hp
Max Torque90Nm /9 kgf-m / 66.3 lb-ft @ 7000 rpm
Fuel Tank Capacity4.4 US gallons / 17.0 L
Weight (Wet/Kerb)450 lbs / 204 kg
Seat Height31.1 inches / 790 mm
Ducati 916 (1997)

All Specifications

Make & Model

ModelDucati 916
Year1997

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven
Displacement916 cc / 55.9 cu in
Bore x Stroke94 x 66 mm
Compression Ratio11.0:1
Max Horsepower83.8 kw / 114 hp
Max Torque90Nm /9 kgf-m / 66.3 lb-ft @ 7000 rpm
Engine Management SystemWeber I.A.W. CPU P8 electronic indirect injection
Lubrication SystemWet sump
Cooling SystemLiquid cooled

Performance

Top Speed255.1 km/h / 158.5 mph

Transmission

ClutchDry, multiplate
Gearbox6 Speed
Primary Drive Ratio2:1 (31/62)
Gear Ratios1st 2.466 / 2nd 1.765 / 3rd 1.350 / 4th 1.091 / 5th 0.958 / 6th 0.857
Final DriveChain

Electrical & Electronics System

Battery12V 16Ah
StarterElectric

Chassis & Suspension

Frame TypeSteel, Trellis frame
Front Suspension43 mm Adjustable Showa GD051 inverted fork
Front Suspension Travel5.0 inches / 127 mm
Rear SuspensionShowa GD52-007-02, rising rate progressive linkage adjustable monoshock
Rear Suspension Travel5.1 inches / 130 mm
RakeAdjustable 24o- 25o
Trail94 – 100 mm / 3.7 – 3.9 in

Wheels & Brakes

Front Wheel/Rim Size3.50 x 17
Front Tire Size120/70 ZR17
Rear Tire Size190/50 ZR17 or 180/55 ZR17
Front Brakes2 x 320 mm Discs, 4 piston calipers
Rear BrakesSingle 220 disc, 2 piston caliper

Dimension & Weights

Seat Height31.1 inches / 790 mm
Wheelbase56.6 inches / 1410 mm
Fuel Tank Capacity4.4 US gallons / 17.0 L
Wet (kerb/curb) Weight450 lbs / 204 kg
Dry Weight198 kg / 436 lbs

Features

  • Here is the list of key features:
  • Four stroke, 90 L twin cylinder engine
  • DOHC desmodromic 4 valve per cylinder
  • Belt driven
  • Liquid-cooled engine
  • Eight-valve design
  • Desmodromic valves
  • Weber fuel-injection system
  • Larger, curved radiator
  • Large airbox with intakes from the fairing nose
  • New exhaust system
  • Revised chassis design with steel ladder frame and tubular aluminium rear subframe
  • Second rear engine mount for extra rigidity
  • Aluminium swingarm with 190-section rear tyre
  • Adjustable steering geometry
  • Horizontally mounted steering damper
  • Vertically adjustable Showa shock
  • 43mm upside-down forks from Japanese firm
  • Brembo braking system
