Ducati 916 (1996)

Ducati 916 (1996)

The Ducati 916: a motorcycle that single-handedly redefined the boundaries of performance and style in the world of superbikes. Its legendary 90-degree twin cylinder engine, boasting an astonishing 108 horsepower at 9000 rpm, was years ahead of its time, with liquid cooling, ram-air induction, and electronic fuel injection making it a technological tour-de-force.

This is no ordinary bike – every detail has been meticulously crafted to deliver the ultimate riding experience. From the fully adjustable USD forks to the Brembo brakes and hydraulic steering damper, the 916 exudes a sense of precision and control that’s simply unmatched in its class.

But what truly sets the Ducati 916 apart is its sublime engine character – smooth, responsive, and incredibly exhilarating as it unwinds to its 9000 rpm redline. Whether carving through twisties or devouring the open road, this bike is an absolute joy to ride, its sheer performance and handling prowess making every moment a thrill. The Ducati 916: a true masterpiece of motorcycle engineering that will leave you breathless.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven
Engine Capacity916 cc / 55.9 cu in
Max Power83.8 kw / 114 hp
Max Torque90Nm /9 kgf-m / 66.3 lb-ft @ 7000 rpm
Fuel Tank Capacity4.4 US gallons / 17.0 L
Weight (Wet/Kerb)450 lbs / 204 kg
Seat Height31.1 inches / 790 mm
Ducati 916 (1996)

All Specifications

Make & Model

ModelDucati 916
Year1996

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valve per cylinder, belt driven
Displacement916 cc / 55.9 cu in
Bore x Stroke94 x 66 mm
Compression Ratio11.0:1
Max Horsepower83.8 kw / 114 hp
Max Torque90Nm /9 kgf-m / 66.3 lb-ft @ 7000 rpm
Engine Management SystemWeber I.A.W. CPU P8 electronic indirect injection
Lubrication SystemWet sump
Cooling SystemLiquid cooled

Performance

Top Speed255.1 km/h / 158.5 mph

Transmission

ClutchDry, multiplate
Gearbox6 Speed
Primary Drive Ratio2:1 (31/62)
Gear Ratios1st 2.466 / 2nd 1.765 / 3rd 1.350 / 4th 1.091 / 5th 0.958 / 6th 0.857
Final DriveChain

Electrical & Electronics System

Battery12V 16Ah
StarterElectric

Chassis & Suspension

Frame TypeSteel, Trellis frame
Front Suspension43 mm Adjustable Showa GD051 inverted fork
Front Suspension Travel5.0 inches / 127 mm
Rear SuspensionShowa GD52-007-02, rising rate progressive linkage adjustable monoshock
Rear Suspension Travel5.1 inches / 130 mm
RakeAdjustable 24o- 25o
Trail94 – 100 mm / 3.7 – 3.9 in

Wheels & Brakes

Front Wheel/Rim Size3.50 x 17
Front Tire Size120/70 ZR17
Rear Tire Size190/50 ZR17 or 180/55 ZR17
Front Brakes2 x 320 mm Discs, 4 piston calipers
Rear BrakesSingle 220 disc, 2 piston caliper

Dimension & Weights

Seat Height31.1 inches / 790 mm
Wheelbase56.6 inches / 1410 mm
Fuel Tank Capacity4.4 US gallons / 17.0 L
Wet (kerb/curb) Weight450 lbs / 204 kg
Dry Weight198 kg / 436 lbs

Features

  • Four-stroke 90 L twin cylinder engine
  • DOHC design
  • Desmodromic 4 valve per cylinder
  • Belt driven
  • 108 hp at 9000 rpm
  • Liquid cooling with ram-air induction
  • Electronic fuel injection
  • Fully adjustable suspension
  • USD forks
  • Brembo brakes
  • Hydraulic steering damper
  • Chromoly tubular steel trellis-style frame
  • Adjustable steering-head angle (23.5 – 24.5 degrees)
  • Self-retracting side stand
