Ducati 900SS Imola (1976)

Ducati 900SS Imola (1976)

The Ducati 900SS Imola is a masterclass in Italian design philosophy, where the rider’s needs take precedence over brute engine power. Its four-stroke twin cylinder engine, with SOHC and 2 valves per cylinder, produces a liquid-smooth motor that sings through its Conti muffler.

The bike’s beauty lies not just in its sleek bodywork, but also in its rideability. With an easy-to-use broad powerband and punchy low-end torque, the Ducati 900SS Imola is a joy to navigate twisties and mountain roads alike.

This motorcycle’s magic lies in its ability to inspire confidence and friendliness, much like its predecessor, the Ducati 750SS. It’s a testament to Italian design principles that put the rider at ease, allowing them to fully utilize their skills on the road.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Engine Capacity864 cc / 52.7 cu in
Max Power58.8 kw / 80 hp
Fuel Tank Capacity20 L / 5.3 US gal / 4.4 Imp gal
Seat Height29.9 inches / 760 mm
Ducati 900SS Imola (1976)

All Specifications

Make & Model

ModelDucati 900SS Imola
Year1976

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Displacement864 cc / 52.7 cu in
Bore x Stroke86 x 74.4 mm
Compression Ratio9.5:1
Max Horsepower58.8 kw / 80 hp
Engine Management System2 x Dell’Orto PHM 40 A, B or C carburetors
Cooling SystemAir cooled

Performance

Top Speed217 km/h / 135mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.187:1 (32/70)
Gear Ratios1st 2.237 / 2nd 1.562 / 3rd 1.203 / 4th 1.000 / 5th 0.887
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12N/12A-4A-12V
StarterKick (electric as an option)

Chassis & Suspension

Front Suspension38 mm Marzocchi fork
Rear SuspensionMarzocchi 310 mm dual shocks, 3-way adjustable

Wheels & Brakes

Front Wheel/Rim Size3.50 – 18
Rear Wheel/Rim Size4.00 – 18
Front Brakes2 x 280mm Disc, 1 piston caliper
Rear BrakesSingle 229 mm disc

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width675 mm / 26.6 in
Overall Height1050 mm / 41.3 in
Seat Height29.9 inches / 760 mm
Wheelbase59.0 inches / 1500 mm
Fuel Tank Capacity20 L / 5.3 US gal / 4.4 Imp gal
Dry Weight188 kg / 414 lbs

Features

  • Four stroke engine
  • 90L twin cylinder engine
  • SOHC (Single Overhead Camshaft) design
  • 2 valves per cylinder
  • Bevel gear driven transmission
  • Available since 1977
  • Aluminum bodywork
  • Liquid-smooth motor
  • Conti muffler music
  • Broad powerband and punchy low-end torque
  • Easy-to-use engine
  • Confidence-inspiring handling
  • Friendly feel on the road
  • Designed around the rider, not the engine
  • Handles well on both backroads and highways
