Ducati 900SS (1993 – 94)

Ducati 900SS (1993 - 94)

The Ducati 900SS is a masterclass in Italian design and engineering, delivering a riding experience that’s as visceral as it is precise.

Built on a platform honed from competition roots, this bike is all about agility and responsiveness. Its liquid-cooled, four-valve engine pumps out a potent punch of power, perfectly complemented by the smooth delivery of its Mikuni fuel injection system.

The 900SS’s handling prowess is legendary, with a steep rake and reduced wheelbase allowing for razor-sharp turns and effortless changes in direction. The Showa front forks and Brembo brakes provide reassuring feedback and control, while the raised clip-on bars and lowered foot-pegs further enhance its sporting credentials.

And so, the Ducati 900SS remains an unforgettable experience that will leave even the most jaded riders grinning from ear to ear – a true icon of two-wheeled machinery.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, desmodromic 2 valves per cylinder, belt driven
Engine Capacity904 cc / 55.2 cu in
Max Power61.8 kw / 84 hp
Max Torque84 Nm / 8.6 kgf-m / 62 ft-lb @ 6400 rpm
Fuel Tank Capacity17.5 L / 4.6 US gal / 3.8 Imp gal
Weight (Wet/Kerb)424 lbs / 192.5 kg
Seat Height30.7 inches / 780 mm
Ducati 900SS (1993 - 94)

All Specifications

Make & Model

ModelDucati 900SS
Year1993 – 94

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, desmodromic 2 valves per cylinder, belt driven
Displacement904 cc / 55.2 cu in
Bore x Stroke92 x 68 mm
Compression Ratio9.2:1
Max Horsepower61.8 kw / 84 hp
Max Torque84 Nm / 8.6 kgf-m / 62 ft-lb @ 6400 rpm
Engine Management SystemMikuni BDST 38-B67
Cooling SystemAir cooled

Performance

Top Speed219.4 km/h / 136.3 mph

Transmission

ClutchDry, multiplate
Gearbox6 Speed
Primary Drive Ratio2.000:1 (31/62)
Gear Ratios1st 2.466 / 2nd 1.764 / 3rd 1.350 / 4th 1.091 / 5th 0.958 / 6th 0.857:1
Final DriveChain

Electrical & Electronics System

Battery12V 16Ah
StarterElectric

Chassis & Suspension

Front Suspension41 mm Showafully adjustable inverted fork
Rear SuspensionProgressive type with adjustable Showa GD monoshock
Rake25o
Trail104 mm / 4.1 in

Wheels & Brakes

Front Tire Size120/70-17
Rear Tire Size170/60-17
Front Brakes2 x 320 mm discs
Rear BrakesSingle 245 mm disc

Dimension & Weights

Overall Length2020 mm / 79.5 in
Overall Width710 mm / 28.0 in
Overall Height1110 mm / 43.7 in
Seat Height30.7 inches / 780 mm
Wheelbase55.5 inches / 1410 mm
Fuel Tank Capacity17.5 L / 4.6 US gal / 3.8 Imp gal
Wet (kerb/curb) Weight424 lbs / 192.5 kg
Dry Weight183 kg / 403 lbs

Features

  • Ducati 900 SS
  • Liquid-cooled engine
  • Fuel-injected
  • Four-valve competition department design
  • Mikuni flat slide carburetors (replacing Weber)
  • Showa adjustable front forks
  • Brembo disc brakes
  • Stepped rake of 25 degrees
  • Shorter swing-arm
  • Reduced wheelbase
  • Longer rear shock absorber
  • Clip-on handlebars raised
  • Foot-pegs lowered
