Ducati 848 (2009)

Ducati 848 (2009)

The Ducati 848 is an exceptional middleweight Superbike that embodies the perfect blend of agility, performance, and style. Its lightweight chassis, weighing in at just 168kg (369lb), provides the ideal platform for riders to experience the thrill of a true Ducati Superbike.

With a potent L-Twin Desmo engine delivering 134hp (98.5kW) @ 10,000rpm and an astonishing 70.8lb-ft (9.8kgm) @ 8,250rpm, this bike is ready to dominate both urban streets and racing circuits alike. The Testastretta EVOluzione engine’s smooth and thrilling torque delivery, combined with its iconic features like twin under-seat silencers and a single-sided swingarm, make the 848 an unbeatable package.

From the moment you twist the throttle, it becomes clear that the rules have changed – the Ducati 848 is a new class of Superbike. With its razor-sharp handling, exceptional performance, and unmistakable Italian flair, this bike sets the bar high for all middleweight sport bikes. The Ducati 848 is more than just a motorcycle – it’s an exhilarating riding experience that will leave you breathless.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity848 cc / 51.7 cu in
Max Power98.5 kw / 134 hp
Max Torque96 Nm / 9.8 kgf-m / 70.8 lb-ft / @ 8250rpm
Fuel Tank Capacity4.2 US gallons / 16.0 L
Seat Height32.6 inches / 830 mm
Ducati 848 (2009)

All Specifications

Make & Model

ModelDucati 848
Year2009

Engine

Engine TypeFour stroke, 90Ltwin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement848 cc / 51.7 cu in
Bore x Stroke94 x 61.2 mm
Compression Ratio12.0:1
Max Horsepower98.5 kw / 134 hp
Max Torque96 Nm / 9.8 kgf-m / 70.8 lb-ft / @ 8250rpm
Engine Management SystemMarelli electronic fuel injection, elliptical throttle bodies
Lubrication SystemWet sump
Cooling SystemLiquid cooled
ExhaustLightweight 2-1-2 system with catalytic converter and lambda probe. Twin stainless steel mufflers.

Performance

Top Speed257.8 km/h / 160.2 mph

Transmission

ClutchWet multiplate with hydraulic control
Gearbox6 Speed
Gear Ratios1st 37/15 / 2nd 30/17 / 3rd 28/20 / 4th 26/22 / 5th 24/23 / 6th 23/24
Final DriveChain

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeTubular steel trellis frame in ALS 450
Front SuspensionShowa 43mm fully adjustable upside-down fork
Front Suspension Travel5.0 inches / 127 mm
Rear SuspensionProgressive linkage with fully adjustable Showa monoshock. Aluminium single-sided swingarm.
Rear Suspension Travel5.1 inches / 130 mm
Rake24.5
Trail103 mm / 4.05 in

Wheels & Brakes

Front Tire Size120/70 ZR17
Rear Tire Size180/50 ZR17
Front Brakes2 x 320mm Disc, Brembo 4 piston calipers
Rear BrakesSingle 245 mm disc, Brembo 2 piston caliper

Dimension & Weights

Seat Height32.6 inches / 830 mm
Wheelbase56.3 inches / 1430 mm
Fuel Tank Capacity4.2 US gallons / 16.0 L
Dry Weight168 kg / 370.4 lbs

Features

  • Dry weight: 168kg (369lb)
  • 20kg (44lb) lighter than its predecessor
  • 30% more powerful than its predecessor
  • L-Twin Desmodromic engine
  • Liquid cooled engine
  • 134hp (98.5kW) @ 10,000rpm
  • 70.8lb-ft (9.8kgm) @ 8,250rpm
  • 94mm x 61.2mm bore and stroke
  • 4 valves per cylinder
  • Racing-style elliptical throttle bodies
  • Electronically injected and ignited by Marelli
  • 2-1-2 exhaust system with catalytic converter and lambda probe
  • Euro3 regulations compliant
  • Vacuum die-cast formed crankcases
  • Weight saving of over 3kg (6.5lb)
  • Sophisticated wet clutch
  • 1kg (2.2lb) less weight than previous clutch
  • Greater durability and improved clutch feel
  • Quiet operation
  • Single-sided swingarm
  • Trellis frame
  • Twin under-seat silencers
