Ducati 750GT (1974)

Ducati 750GT (1974)

The Ducati 750GT – a motorcycle that embodies the perfect blend of style, performance, and handling. Its iconic round case bevel engine is a masterpiece of mechanical art, evoking the nostalgia of 1930s aviation radials. With its super torquey motor, this bike pulls like a dream, making it an absolute joy to ride.

Its frame is the most solid of its era, providing exceptional stability and handling prowess that’s unmatched by its contemporaries. While it may feel long and high at low speeds, with surprisingly little steering lock, it’s on another level entirely when tackling high-speed corners on the open road.

As a dreamer, you’ll appreciate the Ducati 750GT’s ability to outclass everything from the 1970s, save for perhaps a Guzzi V7 Sport or LeMans. This bike is truly in a class by itself, and its legendary handling capabilities make it an experience unlike any other. In short, the Ducati 750GT is the ultimate classic motorcycle that will leave you breathless and wanting more.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Engine Capacity45.6 cubic inches / 748 cc
Max Power41.9 kw / 57 hp
Fuel Tank Capacity4.5 US gallons / 17.0 L
Seat Height30.7 inches / 780 mm
Ducati 750GT (1974)

All Specifications

Make & Model

ModelDucati 750GT
Year1974

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, 2 valves per cylinder, bevel gear driven
Displacement45.6 cubic inches / 748 cc
Bore x Stroke80 x 74.4 mm
Compression Ratio8.5:1
Max Horsepower41.9 kw / 57 hp
Engine Management System2 x 30mm Amal R 930/76
Cooling SystemAir cooled

Performance

Top Speed200 km/h / 124 mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.448:1 (29/71)From 1974: 2.187:1 (32/70)
Gear Ratios1st 2.237 / 2nd 1.562 / 3rd 1.203 / 4th 1.000 / 5th 0.887:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12N-12A-4A-12V
StarterKick

Chassis & Suspension

Front Suspension38 mm Marzocchi forkFrom 1974: Ceriani fork
Rear SuspensionDual shocks, Marzocchi 305 mm, 3-way adjustable

Wheels & Brakes

Front Tire Size3.25-19
Rear Tire Size3.50-18
Front BrakesSingle 280mm disc
Rear Brakes200 mm Drum

Dimension & Weights

Seat Height30.7 inches / 780 mm
Wheelbase60.2 inches / 1530 mm
Fuel Tank Capacity4.5 US gallons / 17.0 L
Dry Weight185 kg / 408 lbs

Features

  • 90 degree V-angle engine
  • Round case bevel engine design
  • Contis for improved performance
  • Super torquey engine
  • Engine sounds like “armageddon”
  • Chain-driven transmission
  • Light weight
  • Alloy forks on front end
  • Airy front end design
  • Greater ground clearance
  • High-speed stability
  • Excellent handling and cornering
  • Low center of gravity
  • Reliable quality workmanship
  • Strong, solid frame
  • Good power delivery
  • Smooth engine performance
