Ducati 750 Supersport (1997)

Ducati 750 Supersport (1997)

The Ducati 750 Supersport is a masterpiece of Italian engineering, boasting an impressive four-stroke, 90L twin-cylinder engine that unleashes a torrent of power and character.

With its Desmodromic valve actuation system and 4 valves per cylinder, this potent V-twin pumps out a thrilling soundtrack as it devours the road. The belt-driven configuration adds to the bike’s sleek and sophisticated demeanor.

The riding experience is nothing short of exhilarating, with the Ducati 750 Supersport effortlessly carving through corners and accelerating with breathtaking speed. Its responsive handling and razor-sharp reflexes make it an absolute joy to ride, and a true embodiment of Italian motorcycling heritage.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Engine Capacity45.6 cubic inches / 748 cc
Max Power48.5 kw / 66 hp
Max Torque72 Nm / 7.3 kgf-m / 53.1 ft-lb @ 6500 rpm
Fuel Tank Capacity17.5 L / 4.6 US gal / 3.8 Imp gal
Weight (Wet/Kerb)416 lbs / 188 kg
Seat Height30.7 inches / 780 mm
Ducati 750 Supersport (1997)

All Specifications

Make & Model

ModelDucati 750 Supersport
Year1997

Engine

Engine TypeFour stroke, 90Ltwin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Displacement45.6 cubic inches / 748 cc
Bore x Stroke88 x 61.5 mm
Compression Ratio9.5:1
Max Horsepower48.5 kw / 66 hp
Max Torque72 Nm / 7.3 kgf-m / 53.1 ft-lb @ 6500 rpm
Engine Management SystemFuel injection
Cooling SystemAir cooled

Performance

Top Speed220 km/h / 124 mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.000:1 (31/62)
Gear Ratios1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12V 14Ah
StarterElectric

Chassis & Suspension

Front SuspensionMarzocchi 40 USD/E inverted telescopic fork
Front Suspension Travel4.7 inches / 119 mm
Rear SuspensionShowa GD 022-007-OXmonoshock,cantilever swingarm
Rear Suspension Travel5.3 inches / 135 mm
Rake25
Trail104 mm / 4.1 in

Wheels & Brakes

Front Wheel/Rim Size3.50 x 17
Front Tire Size120/60-17, Dunlop Sportmax Radial
Rear Wheel/Rim Size5.50 x 17
Rear Tire Size170/60-17,Dunlop Sportmax Radial
Front Brakes2 x 320 mm Discs, 2 piston calipers
Rear BrakesSingle 245 mm disc, 2 piston caliper

Dimension & Weights

Overall Length2000 mm / 78.7 in
Overall Width730 mm / 28.7 in
Overall Height1125 mm / 44.3 in
Seat Height30.7 inches / 780 mm
Wheelbase55.5 inches / 1410 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity17.5 L / 4.6 US gal / 3.8 Imp gal
Wet (kerb/curb) Weight416 lbs / 188 kg
Dry Weight176 kg / 388 lbs

Features

  • Four-stroke engine
  • 90L twin-cylinder configuration
  • Double Overhead Camshaft (DOHC) design
  • Desmodromic valve actuation system
  • 4 valves per cylinder
  • Belt-driven crankshaft
