Ducati 750 Supersport (1996)

Ducati 750 Supersport (1996)

The Italian marques are setting the bar high with their latest offerings, but one bike stands out from the pack: the Ducati 750 Supersport. This air-cooled parallel-twin packs a punch, reaching an impressive 130mph and boasting top-notch chassis components that would make even a works team proud.

Its engine character is defined by a smooth, linear power delivery, with the Ducati’s signature desmodromic valve actuation system providing seamless performance. The ride experience is equally as compelling, with precise handling and a responsive feel that encourages spirited riding.

While its rivals may try to keep pace, the Ducati 750 Supersport has already proven itself to be a formidable contender in the world of sportsbikes. With its unique blend of Italian flair and exceptional performance, this bike is sure to leave a lasting impression on riders who crave excitement and style.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Engine Capacity45.6 cubic inches / 748 cc
Max Power48.5 kw / 66 hp
Max Torque72 Nm / 7.3 kgf-m / 53.1 ft-lb @ 6500 rpm
Fuel Tank Capacity17.5 L / 4.6 US gal / 3.8 Imp gal
Weight (Wet/Kerb)416 lbs / 188 kg
Seat Height30.7 inches / 780 mm
Ducati 750 Supersport (1996)

All Specifications

Make & Model

ModelDucati 750 Supersport
Year1996

Engine

Engine TypeFour stroke, 90Ltwin cylinder, DOHC, desmodromic 4 valves per cylinder, belt driven
Displacement45.6 cubic inches / 748 cc
Bore x Stroke88 x 61.5 mm
Compression Ratio9.0:1
Max Horsepower48.5 kw / 66 hp
Max Torque72 Nm / 7.3 kgf-m / 53.1 ft-lb @ 6500 rpm
Engine Management SystemFuel injection
Cooling SystemAir cooled

Performance

Top Speed220 km/h / 124 mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.000:1 (31/62)
Gear Ratios1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12V 14Ah
StarterElectric

Chassis & Suspension

Front SuspensionMarzocchi 40 USD/E inverted telescopic fork
Front Suspension Travel4.7 inches / 119 mm
Rear SuspensionShowa GD 022-007-OXmonoshock,cantilever swingarm
Rear Suspension Travel5.3 inches / 135 mm
Rake25
Trail104 mm / 4.1 in

Wheels & Brakes

Front Wheel/Rim Size3.50 x 17
Front Tire Size120/60-17, Dunlop Sportmax Radial
Rear Wheel/Rim Size5.50 x 17
Rear Tire Size170/60-17,Dunlop Sportmax Radial
Front Brakes2 x 320 mm Discs, 2 piston calipers
Rear BrakesSingle 245 mm disc, 2 piston caliper

Dimension & Weights

Overall Length2000 mm / 78.7 in
Overall Width730 mm / 28.7 in
Overall Height1125 mm / 44.3 in
Seat Height30.7 inches / 780 mm
Wheelbase55.5 inches / 1410 mm
Ground Clearance130 mm / 5.1 in
Fuel Tank Capacity17.5 L / 4.6 US gal / 3.8 Imp gal
Wet (kerb/curb) Weight416 lbs / 188 kg
Dry Weight176 kg / 388 lbs

Features

  • Four stroke engine
  • 90L twin cylinder
  • DOHC
  • Desmodromic 4 valves per cylinder
  • Belt driven
  • Laverda 650 Sport
  • Air-cooled parallel-twin
  • 130mph top speed
  • Top-notch chassis components
  • High quality brakes
  • Suspension, wheels, and tyres
  • Italian mystique
  • Emotive handling
  • 6750 price tag
  • 7bhp at revvy 650 twin
  • 125mph-plus top speed
  • Seductive Italian style
  • Red color scheme
