Ducati 750 F1 Desmo (1986)

Ducati 750 F1 Desmo (1986)

The Ducati 750 F1 Desmo is an iconic superbike that embodies the spirit of Italian engineering and racing heritage. Powered by a four-stroke, air-cooled L-twin cylinder engine with desmodromic valve actuation, this bike exudes a unique character that’s both raw and refined.

Its engine, with two valves per cylinder driven by a SOHC configuration and belt-driven camshaft, delivers a rich, throaty soundtrack that’s unmistakably Ducati. The 750 F1’s trellis frame, twin Dell’Orto carburetors, and Marzocchi suspension all contribute to its exceptional handling and agility on the road or track.

As one of the rarest and most sought-after bikes of its era, with only 1,801 units produced between 1985 and 1986, the Ducati 750 F1 Desmo is a true collector’s item for enthusiasts.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, desmodromic 2 valves per cylinder, belt driven
Engine Capacity748 cc / 45.6 cu in
Max Power55.2 kw / 75 hp
Max Torque70.6Nm / 7.2 kgf-m / 52.1 ft-lb @ 7000 rpm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Seat Height29.5 inches / 750 mm
Ducati 750 F1 Desmo (1986)

All Specifications

Make & Model

ModelDucati 750 F1 Desmo
Year1986

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, desmodromic 2 valves per cylinder, belt driven
Displacement748 cc / 45.6 cu in
Bore x Stroke88 x 61.5 mm
Compression Ratio10.0:1
Max Horsepower55.2 kw / 75 hp
Max Torque70.6Nm / 7.2 kgf-m / 52.1 ft-lb @ 7000 rpm
Engine Management System2 x 36 mm Dell’OrtoPHF36carburetors

Performance

Top Speed200 km/h / 124 mph

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio1.972:1 (36/71)
Gear Ratios1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.966:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12V 14Ah
StarterElectric

Chassis & Suspension

Front Suspension40 mm Forcella Italia fork
Rear SuspensionRound sectionchrome-moly steel swingarm with adjustable (for preload) cantilever mono-shock, Marzocchi PVS 4

Wheels & Brakes

Front Tire Size120/80 V16
Rear Tire Size130/80 V18
Front Brakes2 x 280mm Discs, single piston caliper.
Rear BrakesSingle 260 mm disc

Dimension & Weights

Overall Length2110 mm / 83.1 in
Overall Width690 mm / 27.2 in
Overall Height1130 mm / 44.5 in
Seat Height29.5 inches / 750 mm
Wheelbase55.1 inches / 1400 mm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Dry Weight175 kg / 386 lbs

Features

  • Four stroke engine
  • 90L twin cylinder engine
  • SOHC design
  • Desmodromic valve system
  • 2 valves per cylinder
  • Belt driven
  • Air-cooled L-twin engine acts as a stressed member
  • Trellis frame
  • Twin Dellorto carburetors
  • Brembo discs (twin) at front with single Brembo disc at rear
  • Marzocchi 38mm non-adjustable forks up front
  • Marzocchi monoshock cantilever swingarm in rear
  • Weight of 175 kg (386 lbs)
  • Power output of 62.5 hp at 7500 rpm
  • Top speed of 206 km/h (~130 mph)
