The Ducati 450Scrambler Jupiter is a testament to the Italian manufacturer’s commitment to innovation and performance. This four-stroke, single-cylinder machine boasts an SOHC design and bevel gear drive, delivering an unmistakable engine character that has captivated riders for decades.

With its desmodromic valve gear technology, the 450Scrambler Jupiter was a game-changer in its time, offering impressive performance credentials that left competitors in its dust. Its quarter-mile time of 16.6 seconds is a testament to its raw power and agility.

But what truly sets the Ducati 450Scrambler Jupiter apart is its riding experience. With an individual speedometer and Veglia tachometer, riders are treated to a level of sophistication and precision that was rare in motorcycles at the time. The result is a bike that not only looks iconic but also delivers an unforgettable ride.

The Ducati 450Scrambler Jupiter remains an enduring classic, its unique blend of style and substance continuing to inspire enthusiasts around the world with every twist of the throttle.

Key Specifications

Engine TypeFour stroke, single cylinder, SOHC, bevel gear driven
Engine Capacity435.7 cc / 26.6 cu in
Max Power23 hp / 16.9 kW @ 6500 rpm
Fuel Tank Capacity13 L / 3.4 US gal / 2.9 Imp gal
Seat Height30.3 inches / 770 mm
Ducati 450Scrambler Jupiter (1973 -)

All Specifications

Make & Model

ModelDucati 450Scrambler Jupiter
Year1973 –

Engine

Engine TypeFour stroke, single cylinder, SOHC, bevel gear driven
Displacement435.7 cc / 26.6 cu in
Bore x Stroke86 x 75 mm
Compression Ratio9.3:1
Max Horsepower23 hp / 16.9 kW @ 6500 rpm
Engine Management SystemDell’Orto VHB 29 AD
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.111:1 (27/57)
Gear Ratios1st 2.46 / 2nd 1.73 / 3rd 1.35 / 4th 1.10 / 5th 0.97:1
Final DriveChain

Electrical & Electronics System

BatterySAFA 3L3, 13.5 Ah
StarterKick

Chassis & Suspension

Front Suspension35 mm Marzocchi telescopic fork
Rear SuspensionSwingarm, dual Marzocchi shocks, 3-way adjustable

Wheels & Brakes

Front Tire Size3.50 x 19, Pirelli
Rear Tire Size4.00 x 18, Pirelli
Front BrakesDrum, 180 mm
Rear BrakesDrum, 160 mm

Dimension & Weights

Overall Length2120 mm / 83.5 in
Overall Width940 mm / 37.0 in
Overall Height1150 mm / 45.3 in
Seat Height30.3 inches / 770 mm
Wheelbase54.3 inches / 1380 mm
Fuel Tank Capacity13 L / 3.4 US gal / 2.9 Imp gal
Dry Weight133 kg / 293 lbs

Features

  • Single cylinder engine
  • Four stroke design
  • SOHC configuration
  • Bevel gear driven camshaft
  • Desmodromic valve gear
  • Scrambler model
  • Individual speedometer
  • Veglia tachometer
  • Quarter-mile time of 16.6 seconds
