Ducati 450Scrambler Jupiter (1970 – 71)

Ducati 450Scrambler Jupiter (1970 - 71)

The Ducati 450Scrambler Jupiter embodies the essence of a bygone era, where innovation met passion. A four-stroke, single cylinder engine with SOHC configuration and bevel gear drive provides the perfect blend of power and control.

Its arrival in 1970-71 marked the pinnacle of Ducati’s engineering prowess, marrying the desmodromic valve technology with the Scrambler’s rugged charm. The result was a motorcycle that commanded attention on the track and the road.

The 450Scrambler Jupiter’s impressive performance credentials were showcased through its blistering quarter-mile time of just 16.6 seconds. But it wasn’t just about speed – this bike also boasted an individual speedometer and Veglia tachometer, setting it apart from its contemporaries.

Its iconic status has stood the test of time, ensuring that the Ducati 450Scrambler Jupiter remains a highly sought-after collector’s item for enthusiasts around the world.

Key Specifications

Engine TypeFour stroke, single cylinder, SOHC, bevel gear driven
Engine Capacity435.7 cc / 26.6 cu in
Max Power23 hp / 16.9 kW @ 6500 rpm
Fuel Tank Capacity3.4 US gallons / 13.0 L
Seat Height30.3 inches / 770 mm
Ducati 450Scrambler Jupiter (1970 - 71)

All Specifications

Make & Model

ModelDucati 450Scrambler Jupiter
Year1970 – 71

Engine

Engine TypeFour stroke, single cylinder, SOHC, bevel gear driven
Displacement435.7 cc / 26.6 cu in
Bore x Stroke86 x 75 mm
Compression Ratio9.3:1
Max Horsepower23 hp / 16.9 kW @ 6500 rpm
Engine Management SystemDell’Orto VHB 29 AD
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.111:1 (27/57)
Gear Ratios1st 2.46 / 2nd 1.73 / 3rd 1.35 / 4th 1.10 / 5th 0.97:1
Final DriveChain

Electrical & Electronics System

BatterySAFA 3L3, 13.5 Ah
StarterKick

Chassis & Suspension

Front Suspension35 mm Marzocchi telescopic fork
Rear SuspensionSwingarm, dual Marzocchi shocks, 3-way adjustable

Wheels & Brakes

Front Tire Size3.50 x 19, Pirelli
Rear Tire Size4.00 x 18, Pirelli
Front BrakesDrum, 180 mm
Rear BrakesDrum, 160 mm

Dimension & Weights

Overall Length2120 mm / 83.5 in
Overall Width940 mm / 37.0 in
Overall Height1150 mm / 45.3 in
Seat Height30.3 inches / 770 mm
Wheelbase54.3 inches / 1380 mm
Fuel Tank Capacity3.4 US gallons / 13.0 L
Dry Weight133 kg / 293 lbs

Features

  • Four-stroke engine
  • Single cylinder configuration
  • SOHC design
  • Bevel gear driven
  • Ducati Desmodromic valve gear
  • Individual speedometer
  • Veglia tachometer
  • 16.6-second quarter-mile time
  • Classic design based on the Scrambler model
