Ducati 450Scrambler Jupiter (1968 – 69)

Ducati 450Scrambler Jupiter (1968 - 69)

The Ducati 450Scrambler Jupiter embodies the essence of a bygone era, when innovation met tradition in perfect harmony. This iconic bike boasts a four-stroke single cylinder SOHC engine, its bevel gear driven crankshaft a testament to Ducati’s commitment to precision engineering.

With the introduction of desmodromic valve gear, the 450Scrambler Jupiter revolutionized performance on two wheels. Its impressive power delivery and responsive handling make it a joy to ride, as evidenced by its blistering quarter-mile time of just 16.6 seconds.

As you sit astride this timeless machine, you’ll appreciate the attention to detail that sets it apart from other bikes of its era – the individual speedometer and Veglia tachometer are a masterclass in understated elegance. Whether carving through twisties or cruising down the highway, the Ducati 450Scrambler Jupiter is an experience that will leave you breathless and yearning for more.

Key Specifications

Engine TypeFour stroke, single cylinder, SOHC, bevel gear driven
Engine Capacity435.7 cc / 26.6 cu in
Max Power23 hp / 16.9 kW @ 6500 rpm
Fuel Tank Capacity3.4 US gallons / 13.0 L
Seat Height30.3 inches / 770 mm
Ducati 450Scrambler Jupiter (1968 - 69)

All Specifications

Make & Model

ModelDucati 450Scrambler Jupiter
Year1968 – 69

Engine

Engine TypeFour stroke, single cylinder, SOHC, bevel gear driven
Displacement435.7 cc / 26.6 cu in
Bore x Stroke86 x 75 mm
Compression Ratio9.3:1
Max Horsepower23 hp / 16.9 kW @ 6500 rpm
Engine Management SystemDell’Orto VHB 29 AD
Cooling SystemAir cooled

Performance

Top Speedn/a

Transmission

ClutchWet, multiplate
Gearbox5 Speed
Primary Drive Ratio2.111:1 (27/57)
Gear Ratios1st 2.46 / 2nd 1.73 / 3rd 1.35 / 4th 1.10 / 5th 0.97:1
Final DriveChain

Electrical & Electronics System

BatterySAFA 3L3, 13.5 Ah
StarterKick

Chassis & Suspension

Front Suspension35 mm Marzocchi telescopic fork
Rear SuspensionSwingarm, dual Marzocchi shocks, 3-way adjustable

Wheels & Brakes

Front Tire Size3.50 x 19, Pirelli
Rear Tire Size4.00 x 18, Pirelli
Front BrakesDrum, 180 mm
Rear BrakesDrum, 160 mm

Dimension & Weights

Overall Length2120 mm / 83.5 in
Overall Width940 mm / 37.0 in
Overall Height1150 mm / 45.3 in
Seat Height30.3 inches / 770 mm
Wheelbase54.3 inches / 1380 mm
Fuel Tank Capacity3.4 US gallons / 13.0 L
Dry Weight133 kg / 293 lbs

Features

  • Four stroke
  • Single cylinder engine
  • SOHC design
  • Bevel gear driven
  • Desmodromic valve gear
  • Individual speedometer
  • Veglia tachometer
  • 16.6-second quarter-mile time
  • Ducati Scrambler styling
  • Classic bike design
