Ducati 350 F3 (1987 – 88)

Ducati 350 F3 (1987 - 88)

In the late 1980s, Ducati faced unique market challenges in Japan and Italy, where sport bikes were limited to specific engine capacities.

The 350cc version of the F3, available only in 1986, showcased a more subtle yet still potent iteration of the iconic Italian design. Its 42.5 horsepower engine provided a thrilling riding experience, with its distinctive character mellowed slightly by the smaller displacement.

Basic but effective suspension components, including Marzocchi forks and Brembo callipers, complemented the bike’s agility, allowing riders to carve through twisties with confidence.

The Italian market’s 350 F3 weighed in at a mere 364 pounds, making it an incredibly light and manageable ride. And indeed, its top speed of 110.8 mph was nothing short of impressive for such a compact machine, cementing the Ducati 350 F3 as a true enthusiast’s delight.

Key Specifications

Engine TypeFour stroke, 90L twin cylinder, Desmo SOHC, belt driven
Engine Capacity348.9 cc / 21.3 cu in
Max Power30.9 kw / 42 hp
Max Torque33 Nm / 3.36 kgf-m / 24.3 ft-lb @ 7100 rpm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Seat Height29.5 inches / 750 mm
Ducati 350 F3 (1987 - 88)

All Specifications

Make & Model

ModelDucati 350 F3
Year1987 – 88

Engine

Engine TypeFour stroke, 90L twin cylinder, Desmo SOHC, belt driven
Displacement348.9 cc / 21.3 cu in
Bore x Stroke66 x 51 mm
Compression Ratio10.3:1
Max Horsepower30.9 kw / 42 hp
Max Torque33 Nm / 3.36 kgf-m / 24.3 ft-lb @ 7100 rpm
Engine Management System2 x 30mm Dell’Orto carburetors
Cooling SystemAir cooled

Performance

Top Speed178 km/h / 110.8 mph

Transmission

Gearbox5 Speed
Primary Drive Ratio2.226:1 (31/69)
Gear Ratios1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.931:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12V 14Ah
StarterElectric

Chassis & Suspension

Front Suspension35 mm Marzocchi fork
Rear SuspensionCantilever swingarm, Boge single adjustable shock

Wheels & Brakes

Front Tire Size100/90-18
Rear Tire Size120/80-18
Front Brakes2x 260mmDiscs
Rear BrakesSingle 260mm disc

Dimension & Weights

Overall Length2050 mm / 80.7 in
Overall Width670 mm / 26.4 in
Overall Height900 mm / 34.4 in
Seat Height29.5 inches / 750 mm
Wheelbase55.1 inches / 1400 mm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Dry Weight180 kg/ 397 lbs

Features

  • Ducati F1 in smaller versions (F3) sold in Japan (400 cc)
  • Ducati F3 sold in Italy (350 cc)
  • Red and white color scheme available for Italian market
  • Japanese 400-cc F3 generated 45 horsepower
  • Italian 350 F3 made 42.5 horsepower
  • Marzocchi forks with 35-mm diameter
  • Dual discs with Brembo callipers, 260-mm diameter
  • Weight: 364 pounds (for both models)
  • Top speed of the 350 F3: 110.8 mph
