In the late 1980s, Ducati’s presence in Japan was bolstered by the release of the F3 model, a smaller variant of their iconic F1 designed to circumvent local market restrictions on larger engines.

The Italian 350cc version of the F3, available exclusively for 1986, shared similarities with its Japanese counterpart but boasted an impressive 42.5 horsepower.

Its lightweight frame and basic suspension, featuring 35mm Marzocchi forks and dual Brembo discs, made it a nimble and responsive ride on twisty roads.

The Ducati 350 F3 proved to be a worthy performer, capable of reaching an astonishing 110.8 mph in testing, cementing its place as a thrilling addition to the company’s lineup.

Key Specifications

Engine TypeFour stroke, 90L twin cylinder, Desmo SOHC, belt driven
Engine Capacity348.9 cc / 21.3 cu in
Max Power30.9 kw / 42 hp
Max Torque33 Nm / 3.36 kgf-m / 24.3 ft-lb @ 7100 rpm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Seat Height29.5 inches / 750 mm
Ducati 350 F3 (1986)

All Specifications

Make & Model

ModelDucati 350 F3
Year1986

Engine

Engine TypeFour stroke, 90L twin cylinder, Desmo SOHC, belt driven
Displacement348.9 cc / 21.3 cu in
Bore x Stroke66 x 51 mm
Compression Ratio10.3:1
Max Horsepower30.9 kw / 42 hp
Max Torque33 Nm / 3.36 kgf-m / 24.3 ft-lb @ 7100 rpm
Engine Management System2 x 30mm Dell’Orto carburetors
Cooling SystemAir cooled

Performance

Top Speed178 km/h / 110.8 mph

Transmission

Gearbox5 Speed
Primary Drive Ratio2.226:1 (31/69)
Gear Ratios1st 2.500 / 2nd 1.714 / 3rd 1.333 / 4th 1.074 / 5th 0.931:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 12V 14Ah
StarterElectric

Chassis & Suspension

Front Suspension35 mm Marzocchi fork
Rear SuspensionCantilever swingarm, Boge single adjustable shock

Wheels & Brakes

Front Tire Size100/90-18
Rear Tire Size120/80-18
Front Brakes2x 260mmDiscs
Rear BrakesSingle 260mm disc

Dimension & Weights

Overall Length2050 mm / 80.7 in
Overall Width670 mm / 26.4 in
Overall Height900 mm / 34.4 in
Seat Height29.5 inches / 750 mm
Wheelbase55.1 inches / 1400 mm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Dry Weight180 kg/ 397 lbs

Features

  • 400-cc engine for Japanese market
  • 350-cc engine for Italian market
  • Red and white color scheme available in Italy
  • Limited to smaller engines due to local regulations
  • Produced from 1986-88
  • Fitted with Marzocchi forks
  • Dual disc brakes with Brembo callipers
  • Weighs 364 pounds
  • Japanese model produced 45 horsepower
  • Italian model produced 42.5 horsepower
