The Ducati 125TV Testone is a timeless classic that embodies the essence of Italian motorcycle design and performance. Launched in 1961 as part of Ducati’s line of 125cc bikes, this model boasted an impressive powertrain capable of producing a respectable 6.5 horsepower.
Its single cylinder, four-stroke OHV engine was paired with a double downtube full cradle steel frame and robust full-width drum brakes, making it a formidable ride on the open road. The 125TV Testone also featured striking styling cues that set it apart from its contemporaries, including Taglioni’s revolutionary sporting designs.
With over 10,000 units sold in 1956 alone, the Ducati 125TV Testone cemented its place as one of the most popular motorcycles of its time. Its enduring legacy is a testament to its exceptional performance and design.
Key Specifications
Engine Type
Four stroke, single-cylinder, OHC, bevel gear driven
Engine Capacity
124.4 cc / 7.6 cu in
Max Power
4.8 kw / 6.5 hp
Seat Height
31.1 inches / 790 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati 125TV Testone
Year
1962 – 68
Engine
Engine Type
Four stroke, single-cylinder, OHC, bevel gear driven
Displacement
124.4 cc / 7.6 cu in
Bore x Stroke
55.2 x 52 mm
Compression Ratio
7.0:1
Max Horsepower
4.8 kw / 6.5 hp
Engine Management System
Dell’Orto UB18BS or ME18BS carburetor
Lubrication System
Forced oil sump
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate
Gearbox
4 Speed
Gear Ratios
1st 2.69 / 2nd 1.85 / 3rd 1.36 / 4th 1.00:1
Final Drive
Chain
Electrical & Electronics System
Battery
SAFA 3L3, 13.5 Ah
Starter
Kick
Chassis & Suspension
Frame Type
Twin tubular downpipe cradle
Front Suspension
Hydraulically damped telescopic forks, Marzocci
Rear Suspension
Swingarm, dual shocks, 3-way adjustable
Wheels & Brakes
Front Tire Size
2.75 – 16
Rear Tire Size
2.75 – 16
Front Brakes
Drum, 123 mm
Rear Brakes
Drum, 123 mm
Dimension & Weights
Seat Height
31.1 inches / 790 mm
Features
Single cylinder, four-stroke OHV engine
125cc powertrain
Double downtube full cradle steel frame
Full-width drum brakes
Produced an output of 6.5 horsepower
Introduced in 1956
Sold over 10,000 units in 1956
Featured Taglionis revolutionary sporting designs
Available as a Turismo (125 T) or Turismo Veloce (125 TV)
Built by Ducati from 1956 to 1960
