Ducati 1199S Panigale (2013)

Ducati 1199S Panigale (2013)

The highly anticipated 1199S Panigale has finally arrived, boasting a host of cutting-edge features that redefine the boundaries of performance and sophistication. At its heart lies the potent Superquadro engine, whose 195 horsepower and 98 lb-ft torque output are harnessed through a sophisticated 2-1-2 exhaust system.

The Ducati Electronic Suspension (DES) takes center stage on this model, paired with an adjustable steering damper and forged Marchesini wheels that shave precious pounds from the overall weight. LED headlights and an Aero kit further emphasize the Panigale’s sleek, aerodynamic presence.

But what truly sets the 1199S apart is its ability to adapt to any riding style or environment. Ducati Riding Modes seamlessly integrate DTC, DQS, EBC, and Power Mode into a cohesive whole, allowing riders to customize their experience with precision and ease.

As you sink into the ergonomic triangle of the Panigale’s innovative chassis, one thing becomes clear: this is not just another motorcycle – it’s an extension of your being, an expression of raw power and unbridled freedom.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity1199 cc / 71.2 cu in
Max Power143 kw / 195 hp
Max Torque132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Fuel Tank Capacity17 L / 4.5 US gal / 3.7 Imp gal
Seat Height32.4 inches / 824 mm
Ducati 1199S Panigale (2013)

All Specifications

Make & Model

ModelDucati 1199S Panigale
Year2013

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement1199 cc / 71.2 cu in
Bore x Stroke112 x 60.8 mm
Compression Ratio12.5:1
Max Horsepower143 kw / 195 hp
Max Torque132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Engine Management SystemMitsubishi EFI, Full ride-by-wire elliptical throttle bodies
Lubrication SystemWet sump
Cooling SystemLiquid cooled
Exhaust2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum outer sleeves

Performance

Top Speed292 km/h / 181mph

Transmission

ClutchSlipper and self-servo wet multiplate clutch with hydraulic control
Gearbox6 Speed
Gear Ratios1st 37/15, 2nd 30/16, 3rd 27/18, 4th 25/20, 5th 24/22, 6th 23/24
Final DriveChain 525; front sprocket 15; rear sprocket 39

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMonocoque aluminum
Front Suspensionhlins NIX30 43mm with TiN, fully adjustable usd fork.Electronic compression and rebound damping adjustment
Front Suspension Travel4.72 inches / 120 mm
Rear SuspensionFully adjustablehlinsTTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm
Rear Suspension Travel5.12 inches / 130 mm
Rake24.5
Trail100 mm / 3.9 in

Wheels & Brakes

Front Tire Size120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear Tire Size200/55 ZR14 Pirelli Diablo Supercorsa SP
Front Brakes2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers, ABS optional +2.5kg (+5.5lb)
Rear BrakesSingle 245 mm disc, 2 piston caliper

Dimension & Weights

Seat Height32.4 inches / 824 mm
Wheelbase56.6 inches / 1437 mm
Fuel Tank Capacity17 L / 4.5 US gal / 3.7 Imp gal
Dry Weight164 kg / 361.5 lbs

Features

  • 2-1-2 exhaust system with catalytic converter and 2 lambda probes
  • Twin stainless steel mufflers with aluminum outer sleeves
  • Hlins NIX30 43mm fork with TiN, fully adjustable USD
  • Electronic compression and rebound damping adjustment
  • Hlins TTX36 unit with electronic compression and rebound damping adjustment
  • Fully adjustable linkage: Progressive/flat
  • Aluminum single-sided swingarm
  • Ducati Electronic Suspension (DES)
  • Adjustable steering damper by hlins
  • Super lightweight forged and machined Marchesini wheels
  • Carbon fibre front mudguard
  • Full LED headlights
  • Aero kit with wider fairing top-section
  • DTC (Ducati Traction Control)
  • DQS (Ducati Quick Shift)
  • EBC (Engine Brake Control)
  • Power Mode
  • Ducati Riding Modes
Ducati 1199S Panigale (2013)
Ducati 1199S Panigale (2013)
Ducati 1199S Panigale (2013)
Ducati 1199S Panigale (2013)
