The new Ducati 1199R Panigale is a masterpiece of performance and technology, born from the world of competitive racing. Its Superquadro engine boasts incredible engineering achievements, including titanium con-rod pistons, a lighter crankshaft flywheel, and DLC-coated rocker-arms that allow it to rev 500rpm higher.
The result is an unparalleled riding experience, with breathtaking acceleration and agility on the track. The R model’s list of enhancements includes a high-penetration racing screen, machined alloy fairing mirror caps, and a full Termignoni exhaust system with dedicated ECU mapping for track use only.
With its impressive power increase and 15-41 final drive ratio, this bike is truly in a league of its own. The Ducati 1199R Panigale is the ultimate expression of Italian engineering and design, offering an experience that is nothing short of exhilarating perfection on two wheels.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity
1199 cc / 71.2 cu in
Max Power
143 kw / 195 hp
Max Torque
132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Fuel Tank Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Seat Height
32.4 inches / 824 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati 1199R Panigale
Year
2014
Engine
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement
1199 cc / 71.2 cu in
Bore x Stroke
112 x 60.8 mm
Compression Ratio
12.5:1
Max Horsepower
143 kw / 195 hp
Max Torque
132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Engine Management System
Mitsubishi EFI, Full ride-by-wire elliptical throttle bodies
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum outer sleeves
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Digital unit with TFT colour display: rev counter, speed, gear selected, odometer [Men 1: trip 1, trip 2, trip fuel], coolant temp [Men 2: average and actual fuel comsumption, average speed, trip time, air temperature], lap times, selected Riding Mode, DTC level, EBC level, DQS status, ABS level, DDA status (only if mounted), GPS status (only if mounted), SERVICE, diagnostic, clock, full status and/or management of Riding Modes, “”Parking”” mode. Display lay-out: ROAD/TRACK (integrated with Riding Modes). Display backlight colours: DAY/NIGHT (manual or auto selection). Warning lights: oil pressure, neutral, EOBD, turn signals, fuel reserve, high-beam, ABS (if oem), over rev, DTC intervention, immobilizer (in Key-off). DES control (Electronic Suspension). Light control: automatic shutdown while engine start, automatic shutdown after 60s from key-on without engine ignition. All funtions integrated and managed by left and right handlebar switches
Chassis & Suspension
Frame Type
Monocoque aluminum
Front Suspension
hlins NIX30 43mm with TiN, fully adjustable usd fork.Electronic compression and rebound damping adjustment
Front Suspension Travel
4.72 inches / 120 mm
Rear Suspension
Fully adjustablehlins TTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm
Rear Suspension Travel
5.12 inches / 130 mm
Rake
24.5
Trail
100 mm / 3.9 in
Wheels & Brakes
Front Tire Size
120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear Tire Size
200/55 ZR14 Pirelli Diablo Supercorsa SP
Front Brakes
2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers, ABS optional +2.5kg (+5.5lb)
Rear Brakes
Single 245 mm disc, 2 piston caliper
Dimension & Weights
Seat Height
32.4 inches / 824 mm
Wheelbase
56.6 inches / 1437 mm
Fuel Tank Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Dry Weight
164 kg / 361.5 lbs
Features
2-1-2 exhaust system with catalytic converter and 2 lambda probes
Twin stainless steel mufflers with aluminum outer sleeves
hlins NIX30 43mm fork with TiN coating
Fully adjustable USD fork
Electronic compression and rebound damping adjustment for fork
hlins TTX36 unit with electronic compression and rebound damping adjustment
Adjustable linkage: Progressive/flat
Aluminum single-sided swingarm
Titanium piston rods
Carbon fibre bodywork
Ducati Performance racing exhaust
Livery inspired by Ducati Corse
15-41 final drive ratio
4-point adjustable swingarm pivot
Lightweight carbon fibre rear hugger and suspension guard
Carbon fibre protectors for single-sided swingarm and clutch cover
GPS-enhanced Ducati Data Analyzer
ABS braking system with standard equipment
