The 2013 Ducati 1199R Panigale is a beast of an engine, boasting a revised Superquadro L-twin that revs to a staggering 12,000rpm with ease. This updated mill features new Titanium con-rod bearings, a lighter crankshaft flywheel, and DLC-coated rocker arms, all working in harmony to deliver lightning-fast acceleration.
The Panigale R’s electronic package is equally impressive, with a ride-by-wire throttle that’s been recalibrated for razor-sharp response. The 2-1-2 exhaust system has also been tweaked, allowing the bike to breathe more freely and produce an intoxicating soundtrack in the process.
But it’s not just about raw power – the Panigale R is also equipped with advanced electronics, including a fully adjustable Öhlins suspension and a state-of-the-art traction control system. And when you’re on track, the Ducati Riding Modes and DES (Ducati Electronic Suspension) work together to provide unparalleled grip and stability.
The result is an uncompromising, track-focused machine that will push even the most experienced riders to their limits. Whether you’re a seasoned pro or just looking for a thrilling ride, the 2013 Ducati 1199R Panigale is an unforgettable experience.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity
1199 cc / 71.2 cu in
Max Power
143 kw / 195 hp
Max Torque
132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Fuel Tank Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Seat Height
32.4 inches / 824 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati 1199R Panigale
Year
2013
Engine
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement
1199 cc / 71.2 cu in
Bore x Stroke
112 x 60.8 mm
Compression Ratio
12.5:1
Max Horsepower
143 kw / 195 hp
Max Torque
132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Engine Management System
Mitsubishi EFI, Full ride-by-wire elliptical throttle bodies
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum outer sleeves
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Digital unit with TFT colour display: rev counter, speed, gear selected, odometer [Men 1: trip 1, trip 2, trip fuel], coolant temp [Men 2: average and actual fuel comsumption, average speed, trip time, air temperature], lap times, selected Riding Mode, DTC level, EBC level, DQS status, ABS level, DDA status (only if mounted), GPS status (only if mounted), SERVICE, diagnostic, clock, full status and/or management of Riding Modes, “”Parking”” mode. Display lay-out: ROAD/TRACK (integrated with Riding Modes). Display backlight colours: DAY/NIGHT (manual or auto selection). Warning lights: oil pressure, neutral, EOBD, turn signals, fuel reserve, high-beam, ABS (if oem), over rev, DTC intervention, immobilizer (in Key-off). DES control (Electronic Suspension). Light control: automatic shutdown while engine start, automatic shutdown after 60s from key-on without engine ignition. All funtions integrated and managed by left and right handlebar switches
Chassis & Suspension
Frame Type
Monocoquealuminum
Front Suspension
hlins NIX30 43mm with TiN, fully adjustable usd fork.Electronic compression and rebound damping adjustment
Front Suspension Travel
4.72 inches / 120 mm
Rear Suspension
Fully adjustablehlins TTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm
Rear Suspension Travel
5.12 inches / 130 mm
Rake
24.5
Trail
100 mm / 3.9 in
Wheels & Brakes
Front Tire Size
120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear Tire Size
200/55 ZR14 Pirelli Diablo Supercorsa SP
Front Brakes
2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers, ABS optional +2.5kg (+5.5lb)
Rear Brakes
Single 245 mm disc, 2 piston caliper
Dimension & Weights
Seat Height
32.4 inches / 824 mm
Wheelbase
56.6 inches / 1437 mm
Fuel Tank Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Dry Weight
164 kg / 361.5 lbs
Features
Dual 2-1-2 exhaust system with catalytic converter and 2 lambda probes
Twin stainless steel mufflers with aluminum outer sleeves
Fully adjustable USD fork (Hlins NIX30 43mm with TiN)
Electronic compression and rebound damping adjustment
Fully adjustable rear shock absorber (Hlins TTX36 unit, electronic compression and rebound damping adjustment)
Adjustable linkage: Progressive/flat
Aluminum single-sided swingarm
Digital display with TFT color screen
Rev counter, speed, gear selected, odometer, and trip data
Lap times, Riding Mode selection, DTC level, EBC level, DQS status, ABS level, DDA status (if mounted), GPS status (if mounted)
“Parking” mode for reduced power output
Display layout: ROAD/TRACK (integrated with Riding Modes)
Warning lights for oil pressure, neutral, EOBD, turn signals, fuel reserve, high-beam, ABS, over rev, and DTC intervention
DES control (Electronic Suspension) for real-time adjustments
Automatic shutdown while engine start or after 60s from key-on without engine ignition
Updated engine management system and recalibrated ride-by-wire throttle
Titanium con-rods
Lighter crankshaft flywheel
DLC-coated rocker-arms
