Ducati 1199 PanigaleSuperLeggera (2014)

Ducati 1199 PanigaleSuperLeggera (2014)

The Ducati 1199 Panigale SuperLeggera is a masterclass in engineering and design, distilling the Italian manufacturer’s expertise into a lightweight, high-performance masterpiece.

Combining cutting-edge technology with exquisite materials, this limited edition marvel boasts an astonishing power-to-weight ratio of over 200 horsepower to just 155 kilograms. The result is an exhilarating riding experience that defies categorization, as the SuperLeggera devours corners and accelerates with unbridled ferocity.

At its heart lies a potent Desmosedici Stradale engine, its titanium exhaust system singing in perfect harmony with the Brembo M50 Monobloc brakes. The ergonomics are tailored to perfection, while the carbon fibre rear sub-frame and bodywork underscore the SuperLeggera’s commitment to unrelenting performance.

The 1199 Panigale SuperLeggera is an authentic Italian performance statement, forged in the crucible of innovation and style, and limited to just 500 handcrafted examples.

Key Specifications

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic4 titanium valves per cylinder
Engine Capacity1199 cc / 71.2 cu in
Max Power149 kw / 200 hp
Max Torque98.8 ft-lb / 134 nm
Fuel Tank Capacity17 L / 4.5 US gal / 3.7 Imp gal
Weight (Wet/Kerb)390.2 lbs / 177 kg
Seat Height32.48 inches / 830 mm
Ducati 1199 PanigaleSuperLeggera (2014)

All Specifications

Make & Model

ModelDucati 1199 PanigaleSuperLeggera
Year2014

Engine

Engine TypeFour stroke, 90 L twin cylinder, DOHC, desmodromic4 titanium valves per cylinder
Displacement1199 cc / 71.2 cu in
Bore x Stroke112 x 60.8 mm
Compression Ratio13.2:1
Max Horsepower149 kw / 200 hp
Max Torque98.8 ft-lb / 134 nm
Cooling SystemLiquid cooled
Exhaust2-1-2 system in titanium with catalytic converter and 2 lambda probes

Performance

Top Speedn/a

Transmission

ClutchSlipper and self-servo wet multiplate clutch with hydraulic control
Gearbox6 Speed
Gear Ratios1st 37/15 2nd 30/16 3rd 27/18 4th 25/20 5th 24/22 6th 23/24

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMagnesium monocoque
Front Suspensionhlins FL916 43mm with TiN, fully adjustable usd fork. Electronic compression and rebound damping adjustment
Rear SuspensionFully adjustable Ohlins TTX36 unit with titanium spring. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm. 4-point adjustable pivot.

Wheels & Brakes

Front Wheel/Rim Size3-spoke forged in magnesium 3.50″ x 17″
Front Tire Size120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear Wheel/Rim Size3 spoke forged in magnesium 6.00″ x 17″
Rear Tire Size200/55 ZR17 Pirelli Diablo Supercorsa SP
Front Brakes2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc M50 4-piston calipers, Bosch 9ME ABS
Rear BrakesSingle245mm disc, 2-piston caliper

Dimension & Weights

Seat Height32.48 inches / 830 mm
Fuel Tank Capacity17 L / 4.5 US gal / 3.7 Imp gal
Wet (kerb/curb) Weight390.2 lbs / 177 kg
Dry Weight155 kg / 341.7 lbs

Features

  • Fully adjustable usd fork with TiN coating
  • Electronic compression and rebound damping adjustment for fork
  • Ohlins TTX36 rear suspension unit with titanium spring
  • Electronic compression and rebound damping adjustment for rear suspension
  • Adjustable linkage: Progressive/flat
  • Aluminum single-sided swingarm
  • 4-point adjustable pivot on swingarm
  • Magnesium monocoque frame
  • Forged Marchesini magnesium wheels
  • Carbon fibre rear sub-frame
  • Lithium-ion battery (LIB)
  • Full titanium exhaust system with stainless steel headers
  • Many bolts and fasteners made of titanium
  • Titanium con-rods in Superquadro engine
  • Inlet valves with titanium coating
  • Titanium exhaust valves
  • Two-ring pistons for reduced mass and friction
  • Precision balanced crankshaft with tungsten inserts
