The Ducati 1199 Panigale is a masterpiece of Italian engineering, boasting a 2-1-2 exhaust system and a powerful 1198cc engine producing 195 horsepower at 10,000 rpm. The chassis features a lightweight Marzocchi fork and Sachs rear suspension unit, ensuring unparalleled handling and control.
The riding experience is further enhanced by the Ducati Riding Modes, which combine DTC, DQS, EBC, and Power Mode for seamless transitions between riding styles. With its aggressive design and sleek fairings, the 1199 Panigale exudes a sense of raw power and sophistication.
From the winding roads of Tuscany to the high-speed tracks of Europe, this incredible machine is designed to deliver ultimate performance and excitement. Its reduced weight and increased power make it the perfect blend of style and substance, cementing its position as the highest performance Ducati Superbike ever created – the Ducati 1199 Panigale is an uncompromising masterpiece that redefines the limits of motorcycling excellence.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Engine Capacity
1199 cc / 71.2 cu in
Max Power
143 kw / 195 hp
Max Torque
132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Fuel Tank Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Seat Height
32.4 inches / 824 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Ducati 1199 Panigale
Year
2012
Engine
Engine Type
Four stroke, 90 L twin cylinder, DOHC, desmodromic 4 valves per cylinder.
Displacement
1199 cc / 71.2 cu in
Bore x Stroke
112 x 60.8 mm
Compression Ratio
12.5:1
Max Horsepower
143 kw / 195 hp
Max Torque
132 Nm / 13.5 kgf-m /97.4.1 lb-ft / @ 9000rpm
Engine Management System
Mitsubishi EFI, Full ride-by-wire elliptical throttle bodies
Lubrication System
Wet sump
Cooling System
Liquid cooled
Exhaust
2-1-2 system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with alumimum outer sleeves
Performance
Top Speed
287.1 km/h / 178.4mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Monocoque aluminum
Front Suspension
Marzocchi 50 mm pressurized and fully adjustable usd fork with hard anodized aluminum lightweight slider
Front Suspension Travel
4.72 inches / 120 mm
Rear Suspension
Fully adjustable Sachs unit. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm.
Rear Suspension Travel
5.12 inches / 130 mm
Rake
24.5
Trail
100 mm / 3.9 in
Wheels & Brakes
Front Tire Size
120/70 ZR17 Pirelli Diablo Supercorsa SP
Rear Tire Size
200/55 ZR14 Pirelli Diablo Supercorsa SP
Front Brakes
2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers ABS optional +2.5kg (+5.5lb)
Rear Brakes
Single 245 mm disc, 2 piston caliper
Dimension & Weights
Seat Height
32.4 inches / 824 mm
Wheelbase
56.6 inches / 1437 mm
Fuel Tank Capacity
17 L / 4.5 US gal / 3.7 Imp gal
Dry Weight
164 kg / 361.5 lbs
Features
2-1-2 system with catalytic converter and 2 lambda probes
Twin stainless steel mufflers with aluminum outer sleeves
Marzocchi 50mm pressurized and fully adjustable USD fork
Hard anodized aluminum lightweight slider
Fully adjustable Sachs rear suspension unit
Adjustable linkage: Progressive/flat
Aluminum single-sided swingarm
Ducati Riding Modes (DTC, DQS, EBC, Power Mode)
Available with optional ABS
1199cc engine capacity
Design inspired by Italian heritage and racing roots
Compact and lightweight chassis design
Revised ergonomic triangle for improved rider posture
Engine covers and exhaust pipe integrated into fairing surface
