Ducati 1000MHR (Mike Hailwood Replica) (1984)

Ducati 1000MHR (Mike Hailwood Replica) (1984)

The Ducati 1000MHR, a highly sought-after motorcycle that embodies the spirit of racing legend Mike Hailwood.

With its robust bevel engine now boasting a plain bearing crankshaft and a 2mm increase in bore to 88mm, the Mille delivers an impressive 76 horsepower. The revised valve diameters have also resulted in a significant boost in torque, reaching 62lb-ft at 5,500rpm. These upgrades combine for an exhilarating riding experience that pushes the limits of speed.

As you twist the throttle and feel the rush of power, you’ll be hard-pressed to resist the allure of this iconic bike’s raw performance. Its aerodynamic fairing and sleek design make it a head-turner on the road, while its exceptional handling capabilities will leave even the most seasoned riders grinning from ear to ear. The result is an unforgettable experience that will keep you coming back for more – every ride with the Ducati 1000MHR is a thrilling adventure that refuses to be forgotten.

Key Specifications

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, desmodromic 2 valves per cylinder, bevel gear driven
Engine Capacity973 cc / 59.4 cu in
Max Power55.9kW 76 hp @ 6700 rpm
Max Torque84 Nm / 8.6 kgf-m / 62 ft-lb @ 5800 rpm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Seat Height31.5 inches / 800 mm
Ducati 1000MHR (Mike Hailwood Replica) (1984)

All Specifications

Make & Model

ModelDucati 1000MHR (Mike Hailwood Replica)
Year1984

Engine

Engine TypeFour stroke, 90Ltwin cylinder, SOHC, desmodromic 2 valves per cylinder, bevel gear driven
Displacement973 cc / 59.4 cu in
Bore x Stroke88 x 80 mm
Compression Ratio9.3:1
Max Horsepower55.9kW 76 hp @ 6700 rpm
Max Torque84 Nm / 8.6 kgf-m / 62 ft-lb @ 5800 rpm
Engine Management System2 x 40 mm Dell’Orto PHM 40B carburetors

Performance

Top Speed222 km/h / 138 mph

Transmission

Gearbox5 Speed
Primary Drive Ratio1.769:1 (39/69)
Gear Ratios1st 2.720 / 2nd 1.761 / 3rd 1.250 / 4th 1.000 / 5th 0.887:1
Final DriveChain

Electrical & Electronics System

BatteryYuasa 19Ah
StarterElectric

Chassis & Suspension

Front Suspension38 mm Marzocchi oil damped telescopic fork
Rear SuspensionMarzocchi dual shocks, 5-way spring preload adjustable

Wheels & Brakes

Front Tire Size110/90V18
Rear Tire Size130/90V18
Front Brakes2 x 280 mm Discs, 2 piston calipers
Rear BrakesSingle 260 mm disc, 1 piston caliper

Dimension & Weights

Overall Length2200 mm / 86.6 in
Overall Width700 mm / 27.6 in
Overall Height1250 mm / 49.2 in
Seat Height31.5 inches / 800 mm
Wheelbase59.1 inches / 1500 mm
Fuel Tank Capacity18 L / 4.8 US gal / 4.0 Imp gal
Dry Weight196 kg / 430 lbs

Features

  • 973cc displacement
  • Plain bearing crankshaft
  • 88mm bore size
  • 42mm intake valve diameter
  • 38mm exhaust valve diameter
  • 40mm carburetors
  • 76 horsepower output
  • 62lb-ft torque at 5,500rpm
  • Reduced primary gear ratio
  • Top speed of 138mph
  • New frame from the 900S2 model
  • Narrower and taller fairing
  • Silentium mufflers as standard
  • Contis mufflers as an option
  • Air/oil-damped Marzocchi forks at front
  • Adjustable Marzocchi rear shocks
  • Oscam wheels with tubeless tires
