The Cagiva X-3 Raptor is a high-performance motorcycle that embodies the perfect blend of raw power and agility. Its four-stroke, 90-degree V-twin engine produces a thunderous roar as it unleashes its fury, delivering an exhilarating riding experience.
But what truly sets this bike apart is its DOHC (dual overhead camshaft) design, which allows for precise control over each cylinder’s intake and exhaust valves. This results in four valves per cylinder – a configuration commonly found on high-performance engines like the Suzuki DL100.
With its exceptional power delivery and responsive handling, the Cagiva X-3 Raptor is a true thrill-seeker’s dream machine, ready to devour twisties and carve through corners with ease and precision. It’s the ultimate roadster for riders who crave an adrenaline rush with every ride.
Key Specifications
Engine Type
Four stroke, 90 V-twin, DOHC, 4 valves per cylinder (Suzuki DL100)
Engine Capacity
60.7 cubic inches / 996 cc
Max Power
105.5 / 78.7 kW @ 8500 rpm
Max Torque
66.4 ft-lb / 90 nm
Fuel Tank Capacity
4.0 US gallons / 15.2 L
Seat Height
30.3 inches / 770 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva X-3 Raptor
Year
2005
Engine
Engine Type
Four stroke, 90 V-twin, DOHC, 4 valves per cylinder (Suzuki DL100)
Displacement
60.7 cubic inches / 996 cc
Bore x Stroke
11.3:1
Compression Ratio
99 x 66 mm
Max Horsepower
105.5 / 78.7 kW @ 8500 rpm
Max Torque
66.4 ft-lb / 90 nm
Engine Management System
Electronic fuel injection
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
43mm Upside down hydraulic fork
Rear Suspension
Rising rate monoshock preload adjustable
Wheels & Brakes
Front Tire Size
120/70 ZR17
Rear Tire Size
180/55 ZR17
Front Brakes
2x 298mm discs 4 piston calipers
Rear Brakes
Single 220mm disc 2 piston caliper
Dimension & Weights
Seat Height
30.3 inches / 770 mm
Wheelbase
56.7 inches / 1440 mm
Fuel Tank Capacity
4.0 US gallons / 15.2 L
Dry Weight
197 kg / 434 lbs
Features
Four-stroke engine
90 V-twin configuration
Double overhead camshaft (DOHC) design
4 valves per cylinder
