The Cagiva V-Raptor 650 is a high-performance variant of its sibling, boasting a potent four-stroke, 90-degree twin-cylinder engine. This DOHC powerplant unleashes its fury through four valves per cylinder, delivering a thrilling riding experience.
Its aggressive styling, courtesy of a small nosecone and removable carbon-effect seat cowl, sets the V-Raptor apart from its more subdued sibling. However, it’s on the road where this bike truly comes alive, with its responsive handling and razor-sharp steering geometry making it a joy to carve through twisties.
The V-Raptor’s exceptional suspension setup, featuring 43mm Marzocchi upside-down front forks and a longer Sachs rear shock, provides outstanding feedback and composure, even on the most demanding roads. With its potent engine, sport-tuned chassis, and aggressive styling, the Cagiva V-Raptor 650 is an uncompromising riding machine that demands to be ridden hard.
Key Specifications
Engine Type
Four stroke, 90-V-twin, DOHC, 4 valves per cylinder.
Engine Capacity
39.3 cubic inches / 645 cc
Max Power
70 hp / 51 kW @ 9000 rpm
Max Torque
46.8 ft-lb / 63.5 nm
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Seat Height
775 kg / 30.5 in
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva V-Raptor 650
Year
2003 – 2004
Engine
Engine Type
Four stroke, 90-V-twin, DOHC, 4 valves per cylinder.
Displacement
39.3 cubic inches / 645 cc
Bore x Stroke
81 x 62.6 mm
Compression Ratio
11.5:1
Max Horsepower
70 hp / 51 kW @ 9000 rpm
Max Torque
46.8 ft-lb / 63.5 nm
Engine Management System
2 x 39mm Mikuni BDSR39
Cooling System
Liquid cooled
Performance
Top Speed
204.8 km/h
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
High strength steel tubular frame
Front Suspension
43mm Upside down forks
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Monoshock
Rear Suspension Travel
5.4 inches / 138 mm
Wheels & Brakes
Front Tire Size
120/70ZR17
Rear Tire Size
160/60ZR17
Front Brakes
2x 298mm discs4piston calipers
Rear Brakes
Single 220mm disc 2 piston caliper
Dimension & Weights
Seat Height
775 kg / 30.5 in
Wheelbase
56.6 inches / 1438 mm
Ground Clearance
165 mm / 6.5 in
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Dry Weight
180 kg /180.0 kg / 396.8 lbs
Features
Four stroke engine
90-V-twin configuration
DOHC design
4 valves per cylinder
V-Raptor 650 bodywork with nosecone
Removable carbon-effect seat cowl
Upside-down front forks by Marzocchi
Radial tyres
Wider handlebars
Slightly quicker steering geometry than Raptor 650
Sachs rear shock
Longer rear suspension compared to Raptor 650
