The Cagiva V-Raptor 1000 is a behemoth of a motorcycle, boasting a 996cc V-twin engine that’s nothing short of intimidating.
This powerhouse of a bike produces 82kW of raw power, courtesy of the Suzuki TL1000’s rip-snorting V-twin.
With its cavernous airbox and short, stubby carbon tailpipes, this beast is set up to deliver instant, effortless response and eye-squishing acceleration.
Key Specifications
Engine Type
Four stroke, 90 V-twin, DOHC, 4 valves per cylinder (Suzuki DL100)
Engine Capacity
60.7 cubic inches / 996 cc
Max Power
105.5 / 78.7 kW @ 8500 rpm
Max Torque
66.4 ft-lb / 90 nm
Fuel Tank Capacity
4.0 US gallons / 15.2 L
Seat Height
30.3 inches / 770 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva V-Raptor 1000
Year
2000 – 2001
Engine
Engine Type
Four stroke, 90 V-twin, DOHC, 4 valves per cylinder (Suzuki DL100)
Displacement
60.7 cubic inches / 996 cc
Bore x Stroke
11.3:1
Compression Ratio
99 x 66 mm
Max Horsepower
105.5 / 78.7 kW @ 8500 rpm
Max Torque
66.4 ft-lb / 90 nm
Engine Management System
Electronic fuel injection
Performance
Top Speed
232 km/h
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
43mm Upside down hydraulic fork
Rear Suspension
Rising rate monoshock preload adjustable
Wheels & Brakes
Front Tire Size
120/70 ZR17
Rear Tire Size
180/55 ZR17
Front Brakes
2x 298mm discs 4 piston calipers
Rear Brakes
Single 220mm disc 2 piston caliper
Dimension & Weights
Seat Height
30.3 inches / 770 mm
Wheelbase
56.7 inches / 1440 mm
Fuel Tank Capacity
4.0 US gallons / 15.2 L
Dry Weight
197 kg / 434 lbs
Features
Four stroke, 90 V-twin engine
DOHC, 4 valves per cylinder
996cc V-twin engine
82kW of power
Cavernous airbox
Short, stubby carbon tailpipes
Rigidly mounted litre-class twin engine
Instant, effortless response at high speeds
Eye-squishing acceleration
Hits 220 in half a kilometre
Trellis frame design
Three-point upper mounting for unequal coefficients of expansion
Light, positive and abuse-proof clutch
Hefty and solid gearboxes
Positive gearshift feel at high revs
Uneven power delivery at low RPM
