The Cagiva Raptor 650 is an intriguing entry in the middleweight motorcycle market. Its 90-degree V-twin engine, derived from the Suzuki SV650, boasts DOHC configuration and 4 valves per cylinder for a rich, throaty exhaust note.
A key aspect of the Raptor’s appeal lies in its handling dynamics. Weighing in significantly lighter than its TL1000-powered sibling, this bike is more agile and responsive to steering inputs, while its twin 298mm front disc brakes provide ample stopping power.
While it may not match the raw power of its larger counterpart, the Raptor 650 makes up for it with its nimble handling and more manageable ergonomics.
Key Specifications
Engine Type
Four stroke, 90-V-twin, DOHC, 4 valves per cylinder.
Engine Capacity
39.3 cubic inches / 645 cc
Max Power
70 hp / 51 kW @ 9000 rpm
Max Torque
46.8 ft-lb / 63.5 nm
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Seat Height
775 kg / 30.5 in
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Raptor 650
Year
2001 – 2002
Engine
Engine Type
Four stroke, 90-V-twin, DOHC, 4 valves per cylinder.
Displacement
39.3 cubic inches / 645 cc
Bore x Stroke
81 x 62.6 mm
Compression Ratio
11.5:1
Max Horsepower
70 hp / 51 kW @ 9000 rpm
Max Torque
46.8 ft-lb / 63.5 nm
Engine Management System
2 x 39mm Mikuni BDSR39
Cooling System
Liquid cooled
Performance
Top Speed
207 km/h
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
High strength steel tubular frame
Front Suspension
43mm Upside down forks
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Monoshock
Rear Suspension Travel
5.4 inches / 138 mm
Wheels & Brakes
Front Tire Size
120/70ZR17
Rear Tire Size
160/60ZR17
Front Brakes
2x 298mm discs4piston calipers
Rear Brakes
Single 220mm disc 2 piston caliper
Dimension & Weights
Seat Height
775 kg / 30.5 in
Wheelbase
56.6 inches / 1438 mm
Ground Clearance
165 mm / 6.5 in
Fuel Tank Capacity
5.0 US gallons / 19.0 L
Dry Weight
180 kg /180.0 kg / 396.8 lbs
Features
Four stroke engine
90-V-twin configuration
DOHC design
4 valves per cylinder
Suzuki SV650 liquid-cooled V-twin powerplant
Twin 298mm front disc brakes
Narrower 160-section rear tyre
Lighter weight than the Raptor 1000
