The Cagiva Navigator 1000 is a formidable dual-purpose machine that boasts an impressive power-to-weight ratio. Its V-twin engine, borrowed from Suzuki’s TL1000, produces a commanding 73kW of power, making it one of the most powerful trail-styled bikes available.
With its compact chassis and narrow design, the Navigator slices through the air with ease, allowing for exceptional top speeds despite its relatively low weight. The soft suspension and strong brakes work in harmony to tame the engine’s exuberance, ensuring a smooth ride even when pushing the bike to its limits.
The Navigator’s 996cc V-twin motor is a testament to Cagiva’s passion for high-performance engineering, with reconfigured cam profiles delivering maximum torque for effortless acceleration and wheelies. Whether carving through twisty roads or tackling challenging off-road terrain, this Italian muscle machine is sure to leave an indelible mark on the riding experience.
Key Specifications
Engine Type
Four stroke, 90-V-twin, DOHC, 4 valves per cylinder (Suzuki TL1000)
Engine Capacity
60.7 cubic inches / 996 cc
Max Power
99 ho / 73 kW @ 8500 rpm
Max Torque
95 Nm / 9.7 kgf-m @ 7000 rpm
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Weight (Wet/Kerb)
496 lbs / 225 kg
Seat Height
33.5 inches / 850 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Navigator 1000
Year
2004 – 2005
Engine
Engine Type
Four stroke, 90-V-twin, DOHC, 4 valves per cylinder (Suzuki TL1000)
Displacement
60.7 cubic inches / 996 cc
Bore x Stroke
98 X 66 mm
Compression Ratio
11.3:1
Max Horsepower
99 ho / 73 kW @ 8500 rpm
Max Torque
95 Nm / 9.7 kgf-m @ 7000 rpm
Engine Management System
Electronic fuel injection
Cooling System
Liquid cooled
Performance
Top Speed
211.6 km/h
*n/a – information not provided by manufacturer
Transmission
Clutch
Cable-operated multi-plate wet clutch.
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
45mm Telescopic hydraulic fork
Front Suspension Travel
5.9 inches / 150 mm
Rear Suspension
Progressive with hydraulic monoshock, preload and rebound damping adjustable.
Rear Suspension Travel
6.3 inches / 160 mm
Wheels & Brakes
Front Tire Size
110/80-18
Rear Tire Size
150/70-17
Front Brakes
2x 298mm discs 4 piston calipers
Rear Brakes
Single 220mm disc 2 piston caliper
Dimension & Weights
Seat Height
33.5 inches / 850 mm
Ground Clearance
150 mm / 5.9 in
Fuel Tank Capacity
5.3 US gallons / 20.0 L
Wet (kerb/curb) Weight
496 lbs / 225 kg
Dry Weight
210 kg / 463 lbs
Features
Four stroke, 90-V-twin engine
DOHC design
4 valves per cylinder
Hydraulic monoshock suspension
Preload and rebound damping adjustable
Suzuki TL1000 engine
Cagiva’s own exhaust system
Intake system designed by Cagiva
Engine detuned to 73kW
Maximum power output: over 200km/h
Shortened off-road gearing for improved acceleration
996cc displacement
90-degree twin cylinder design
Twin overhead cams
Eight valves per engine
Twin-swirl combustion chambers
Rear suspension with preload and rebound damping adjustment
