The Cagiva Mito SP 525 represents a paradigm shift in two-stroke engine technology. Gone are the days when “two-stroke” implied only raw performance; now it also signifies a deep commitment to environmental care.
The integrated ECS (Electronic Carburetion System) is a masterstroke, developed in collaboration with DellOrto. This cutting-edge system administers precisely the right amount of fuel and oil mix, while governing the ignition system to meet Euro 3 standards. The result is an engine that retains all the advantages of two-stroke power – lightness, performance, and low running costs.
But what truly sets the Mito SP 525 apart is its ability to deliver a unique riding experience. With a potent two-stroke heart beating beneath its sleek bodywork, this bike excels in both urban commuting and spirited twisties. Its agility and responsiveness make it an absolute joy to ride, with every corner taken with precision and control.
The Mito SP 525 has truly rewritten the rulebook on what a modern two-stroke engine should be: capable, efficient, and environmentally friendly.
Key Specifications
Engine Type
Two stroke, single cylinder, electricvariablepower read valve
Engine Capacity
7.6 cubic inches / 125.6 cc
Max Power
25.4 hp / 18.9 kW @ 12000 rpm
Max Torque
16.9 ft-lb / 23 nm
Fuel Tank Capacity
3.7 US gallons / 14.0 L
Seat Height
29.9 inches / 760 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Mito SP 525
Year
2008 – 2009
Engine
Engine Type
Two stroke, single cylinder, electricvariablepower read valve
Displacement
7.6 cubic inches / 125.6 cc
Bore x Stroke
56 x 50.6 mm
Compression Ratio
7.4:1
Max Horsepower
25.4 hp / 18.9 kW @ 12000 rpm
Max Torque
16.9 ft-lb / 23 nm
Engine Management System
Dell’Orto PHBH 25 carburetor
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multiple discs, cable operated
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Aluminium double extruded beam
Front Suspension
40mm Marzocchi telescopic forks
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Progressive with hydralyc shock, adjustable spring preload
Rear Suspension Travel
5.4 inches / 133 mm
Wheels & Brakes
Front Tire Size
110/70 ZR17
Rear Tire Size
150/60 ZR17
Front Brakes
Single 320mm disc 4 piston caliper
Rear Brakes
Single 230mm disc 2 piston caliper
Dimension & Weights
Seat Height
29.9 inches / 760 mm
Wheelbase
54.1 inches / 1375 mm
Ground Clearance
150 mm / 5.9 in
Fuel Tank Capacity
3.7 US gallons / 14.0 L
Dry Weight
129.0 kg / 284.4 lbs
Features
Here are the key features of the Mito 125 from Cagiva:
Integrated ECS (Electronic Carburetion System)
Two-stroke engine with Euro 3 standards
Fuel injection and oil mix administration
Electronic ignition system control unit
Lightness
Performance
Low running costs
Liquid-cooled engine
Fuel-injected engine
