The Cagiva Elefant650 is a behemoth of a motorcycle, born from the grueling Paris-to-Dakar rally where street engines are pushed to their limits in off-road chassis.
Its 90-degree V-twin engine, borrowed from the 650 Alazzurra, is a force to be reckoned with. The desmodromic valve actuation ensures that the engine remains protected from over-rev damage, and its cases have proven unbreakable even after 6,500 miles of P-D pounding.
The Elefant’s sheer size is daunting – its wheelbase is just over 60 inches, seat height is 35 inches, and wet weight is a substantial 454 pounds. However, this bulk belies its incredible agility and handling on both pavement and fireroads.
When you throw the Elefant into a turn, its massive V-twin engine comes alive, delivering instant power and traction that’s hard to match. The Ducati-derived desmo engine may seem counterintuitive for off-road use, but it proves to be an inspired choice, providing incredible durability and smoothness under heavy load.
The Cagiva Elefant650 is not just a dual-purpose motorcycle – it’s a statement of intent from a company that refuses to compromise on performance. It’s a bike that can conquer the toughest terrain with ease, yet still deliver blistering acceleration and handling on paved roads.
Key Specifications
Engine Type
Four stroke, 90 Ltwin cylinder, SOHC, desmodromic 2 valve per cylinder.
Engine Capacity
39.6 cubic inches / 649 cc
Max Power
54 hp / 40 kW @ 8400 rpm
Max Torque
39.8 ft-lb / 54 nm
Fuel Tank Capacity
4.6 US gallons / 17.5 L
Weight (Wet/Kerb)
458.6 lbs / 208 kg
Seat Height
35.6 inches / 905 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Elefant650
Year
1989
Engine
Engine Type
Four stroke, 90 Ltwin cylinder, SOHC, desmodromic 2 valve per cylinder.
Displacement
39.6 cubic inches / 649 cc
Bore x Stroke
82 x 61 mm
Compression Ratio
10.0:1
Max Horsepower
54 hp / 40 kW @ 8400 rpm
Max Torque
39.8 ft-lb / 54 nm
Engine Management System
2x 36mm Dell’Orto carburetors
Cooling System
Air cooled
Performance
Top Speed
179 km/h
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
Air adjustable forks 42mm tubes
Front Suspension Travel
8.6 inches / 220 mm
Rear Suspension
Single shock absorber. adjustable for spring preload
Wheels & Brakes
Front Tire Size
90/90-21
Rear Tire Size
130/90-17
Front Brakes
Single260mmdisc 4 piston caliper
Rear Brakes
Single240mmdisc 2 piston caliper
Dimension & Weights
Seat Height
35.6 inches / 905 mm
Wheelbase
59.8 inches / 1520 mm
Fuel Tank Capacity
4.6 US gallons / 17.5 L
Wet (kerb/curb) Weight
458.6 lbs / 208 kg
Dry Weight
191 kg/ 421 lbs
Features
90-degree V-twin engine
Desmodromic valve actuation
Engine cases are unbreakable
82 x 61.5mm bore and stroke
10.1 compression ratio
Valve sizes identical to Ducati Alazzurra
8500-rpm redline
Five-gear transmission
Solid mounted engine
Aluminum mounts isolate engine from frame rails
Engine is hung by two alloy arms from the backbone
Aluminum cross-member supports engine from the front
Seat height of 35 inches
Wheelbase over 60 inches
Wet weight of 454 pounds
