The Cagiva 900 Elefant is a behemoth of a motorcycle, born from the grueling demands of the Paris-Dakar Rally. This off-road superbike boasts an impressive array of features, including a potent 900cc air and oil-cooled overhead cam V-twin engine with desmodromic valve gear.
The 90-degree V-twin motor produces a healthy 70bhp at 8500rpm, thanks to electronic fuel-injection. However, it’s not just raw power that sets the Elefant apart – its usable spread of torque makes it perfect for navigating treacherous off-road terrain.
A high level of suspension equipment is standard on this desert-racer, with Marzocchi forks and a fully-adjustable Hlins monoshock providing exceptional damping capabilities. Hefty twin front disc brakes and twin-pot Nissin calipers offer plenty of stopping power when needed.
The result is an unstoppable machine that combines brute strength with agility and finesse – the Cagiva 900 Elefant is the ultimate off-road experience.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinder, SOHC, desmodromic 2 valve per cylinder
Engine Capacity
55.1 cubic inches / 904 cc
Max Power
95 hp / 70 kW @ 8500 rpm
Max Torque
57.5 ft-lb / 78 nm
Fuel Tank Capacity
5.8 US gallons / 22.0 L
Seat Height
33.7 inches / 857 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Elefant 900AC CAT
Year
1994
Engine
Engine Type
Four stroke, 90 L twin cylinder, SOHC, desmodromic 2 valve per cylinder
Displacement
55.1 cubic inches / 904 cc
Bore x Stroke
92 x 68 mm
Compression Ratio
9.2:1
Max Horsepower
95 hp / 70 kW @ 8500 rpm
Max Torque
57.5 ft-lb / 78 nm
Engine Management System
Mikuni BDST 38 carburetors
Cooling System
Air cooled
Performance
Top Speed
183.4 km/h / 114. mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Dry Multi-disc
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Double steel tubular cradle
Front Suspension
45mm Showa upside down telescopic forks
Rear Suspension
Rising rate box, monoshock adjustable for preload
Wheels & Brakes
Front Tire Size
100/90-19
Rear Tire Size
140/80-17
Front Brakes
2x 282mm discs 4 piston calipers
Rear Brakes
Single 240mm disc 4 piston caliper
Dimension & Weights
Seat Height
33.7 inches / 857 mm
Wheelbase
61.8 inches / 1570 mm
Ground Clearance
260 mm / 10.2 in
Fuel Tank Capacity
5.8 US gallons / 22.0 L
Dry Weight
204 kg / 449.7 lbs
Features
900cc air and oil-cooled overhead cam 90-degree V-twin motor
Desmodromic valve gear
Electronic fuel-injection
70bhp at 8500rpm
High level of suspension equipment
Marzocchi forks at the front
Hlins multi-adjustable monoshock at the back
Rugged long-travel suspension
Hefty twin front disc brakes
Twin-pot Nissin calipers
Large-capacity fuel tank
Twin-headlamp fairing
Vertiginous seat height of over 35ins
Top speed of 120mph
