The Cagiva 900 Elefant is a behemoth of a machine, born from the unforgiving desert terrain of the Paris-Dakar Rally. This massive off-road superbike combines incredible power and rugged capability with a healthy dose of European flair.
Its 900cc air and oil-cooled V-twin motor delivers a healthy 70bhp at 8500rpm, but it’s the engine’s usable spread of torque that truly sets it apart. Electronic fuel-injection helps to keep the beast under control, while Marzocchi forks and an Hlins multi-adjustable monoshock suspension provide unparalleled off-road capability.
Hefty twin front disc brakes and Nissin calipers ensure you can bring this monster back down to earth when needed, while a large-capacity fuel tank and twin-headlamp fairing complete the essential Paris-Dakar package. The Cagiva 900 Elefant is a true desert warrior, ready to take on even the toughest off-road terrain with confidence and precision.
The Cagiva 900AC CAT (1993) is a testament to its maker’s ability to translate the demands of the Sahara into production reality, offering an unparalleled riding experience for those who dare to tackle the toughest trails.
Key Specifications
Engine Type
Four stroke, 90 L twin cylinder, SOHC, desmodromic 2 valve per cylinder
Engine Capacity
55.1 cubic inches / 904 cc
Max Power
95 hp / 70 kW @ 8500 rpm
Max Torque
57.5 ft-lb / 78 nm
Fuel Tank Capacity
5.8 US gallons / 22.0 L
Seat Height
33.7 inches / 857 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Elefant 900AC CAT
Year
1993
Engine
Engine Type
Four stroke, 90 L twin cylinder, SOHC, desmodromic 2 valve per cylinder
Displacement
55.1 cubic inches / 904 cc
Bore x Stroke
92 x 68 mm
Compression Ratio
9.2:1
Max Horsepower
95 hp / 70 kW @ 8500 rpm
Max Torque
57.5 ft-lb / 78 nm
Engine Management System
Mikuni BDST 38 carburetors
Cooling System
Air cooled
Performance
Top Speed
183.4 km/h / 114. mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Dry Multi-disc
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Double steel tubular cradle
Front Suspension
45mm Showa upside down telescopic forks
Rear Suspension
Rising rate box, monoshock adjustable for preload
Wheels & Brakes
Front Tire Size
100/90-19
Rear Tire Size
140/80-17
Front Brakes
2x 282mm discs 4 piston calipers
Rear Brakes
Single 240mm disc 4 piston caliper
Dimension & Weights
Seat Height
33.7 inches / 857 mm
Wheelbase
61.8 inches / 1570 mm
Ground Clearance
260 mm / 10.2 in
Fuel Tank Capacity
5.8 US gallons / 22.0 L
Dry Weight
204 kg / 449.7 lbs
Features
900cc air and oil-cooled overhead cam 90-degree V-twin motor
Desmodromic valve gear
Electronic fuel-injection
70bhp at 8500rpm
Marzocchi forks as front suspension
Hlins multi-adjustable monoshock as rear suspension
Long-travel suspension for rugged off-road use
Hefty twin front disc brakes with twin-pot Nissin calipers
Large-capacity fuel tank
Twin-headlamp fairing
Vertiginous seat height of over 35ins
Wide spread of power and torque for on-road usability
Top speed of 120mph
Low-reving motor suitable for off-road use
Low gearing for easy acceleration in off-road conditions
Flexible V-twin engine with minimal gear-changes required
