The Cagiva Elefant 200, produced from 1985 to 1986, is an impressive motorcycle that shares many similarities with its smaller sibling, the ELEFANT 125.
Its liquid-cooled engine boasts a lamellar system and carburetor fueling, providing a discreet torque at low speeds. Equipped with six gears, this powertrain delivers a smooth riding experience. The Orologio carburettor is paired with an injection pump connected to the carburetor for optimal lubrication.
The Elefant 200’s stable design features a large 15.5-liter fuel tank and a combination of a front disc brake and rear drum brake for added safety.
Key Specifications
Engine Type
Two stroke, single cylinder
Engine Capacity
11.6 cubic inches / 190 cc
Max Power
27 hp / 19.7 @ 9000 rpm
Max Torque
15.4 ft-lb / 21 nm
Fuel Tank Capacity
4.0 US gallons / 15.5 L
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Cagiva Elefant 200
Year
1985 – 86
Engine
Engine Type
Two stroke, single cylinder
Displacement
11.6 cubic inches / 190 cc
Bore x Stroke
67 x 54 mm
Compression Ratio
11.9:1
Max Horsepower
27 hp / 19.7 @ 9000 rpm
Max Torque
15.4 ft-lb / 21 nm
Engine Management System
Single Dell’Orto premix
Cooling System
Liquid cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Gearbox
6 Speed
Final Drive
Chain
Electrical & Electronics System
Starter
Kick & Electric
Chassis & Suspension
Frame Type
Tubular duplex cradle
Front Suspension
Telescopic forks
Rear Suspension
Alloy single shock soft damp
Wheels & Brakes
Front Tire Size
3.00-21
Rear Tire Size
4.60-17
Front Brakes
Single 240mm disc
Rear Brakes
130mm Drum
Dimension & Weights
Fuel Tank Capacity
4.0 US gallons / 15.5 L
Dry Weight
125 kg / 275.5 lbs
Features
Liquid-coolant engine
Suction coolant system
Lamellar system
Carburetor
Electric and pedal start
Injection pump connected to carburetor
Lubrication system with injection pump
6-speed transmission
“Regina” chain with parastrappi
Front disc brakes
Rear drum brakes
Large fuel tank (15.5 litres)
