The Buell XR9S Lightning: a naked bike that embodies the perfect blend of power and agility. At its heart lies a 45° V-Twin engine, delivering a potent punch with its hydraulic self-adjusting lifters and 2 valves per cylinder.
Its hollow aluminium twin-spar frame not only doubles as the fuel tank but also provides exceptional rigidity and strength. Up front, Showa upside-down forks offer adjustable damping for a tailored ride, while at the rear, a Showa shock absorber allows for similarly precise control.
But it’s on the road where the XR9S truly shines. With its torquey engine and capable chassis, this bike devours twisties with ease, its 6-piston fixed caliper brake system providing reassuring stopping power.
In a class dominated by Ducati’s Monster, the Buell XR9S Lightning is a worthy challenger, offering an unparalleled riding experience that’s equal parts thrilling and precise. The result? A naked bike that’s as raw as it is refined, and one that will leave even the most seasoned riders grinning from ear to ear.
Key Specifications
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve.hydraulic self-adjusting lifters,2 valve per cylinder
Engine Capacity
984 cc / 60 cu in
Max Power
67.1 kw / 92 hp
Max Torque
97 Nm / 9.9 kgf-m / 71.5 ft.lbs @ 5500 rpm
Fuel Tank Capacity
3.7 US gallons / 14.0 L
Seat Height
30.5 inches / 775 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Buell XR9S Lightning
Year
2003
Engine
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve.hydraulic self-adjusting lifters,2 valve per cylinder
Displacement
984 cc / 60 cu in
Bore x Stroke
88.9 x 79.4 mm
Compression Ratio
10.0:1
Max Horsepower
67.1 kw / 92 hp
Max Torque
97 Nm / 9.9 kgf-m / 71.5 ft.lbs @ 5500 rpm
Engine Management System
45 mm Downdraft DDFI fuel injection
Lubrication System
Dry sump
Cooling System
Air cooled
Exhaust
Two-into-one, free breathing
Performance
Top Speed
210.2 km/h / 130.6 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate
Gearbox
5 Speed, constant mesh
Gear Ratios
1st2.69 / 2nd1.85 / 3rd1.43 / 4th1.18 / 5th1.00
Final Drive
Kevlar belt
Electrical & Electronics System
Battery
12V, 12Ah
Starter
Electric
Chassis & Suspension
Frame Type
Hollow aluminium twin-spar frame doubles as the fuel tank
Front Suspension
Showa upside-down forks, adjustable for preload, compression & rebound damping
Front Suspension Travel
4.7 inches / 119 mm
Rear Suspension
Showa shock absorber, adjustable for preload, compression & rebound damping
Hollow aluminum twin-spar frame doubles as fuel tank
Showa upside-down forks with adjustable preload, compression, and rebound damping
Showa shock absorber with adjustable preload, compression, and rebound damping
ZTL-type brake with 6-piston fixed caliper and 375mm single-sided rotor
Stainless steel, floating rotor
Length: 1924 mm / 75.7 in
Width: 831 mm / 32.7 in
Height: 1232 mm / 48.5 in
