The naked-bike class has evolved significantly since Ducati’s iconic Monster sparked this trend in 1992. Today, it’s all about showcasing a torquey engine and a rigid chassis, with minimal bodywork to let the mechanical components shine.
Buell’s Lightning series has been at the forefront of this movement, and its latest iteration is the XR9S. Powered by a 45-degree V-Twin engine, this bike boasts an impressive 120 horsepower and 92 lb-ft of torque, making it an exhilarating ride on twisty roads. The Showa upside-down forks and adjustable shock absorber provide exceptional handling and stability.
As you ride the XR9S Lightning, you’ll feel its exceptional mass centralization and frame rigidity, thanks to Buell’s innovative Trilogy of Technology. The result is a bike that accelerates with ease and hugs corners like a champ. Whether carving through mountain roads or cruising down the highway, this naked bike delivers an unforgettable experience.
The XR9S Lightning embodies the perfect blend of power, handling, and style, cementing its place as one of the top contenders in the naked-bike class.
Key Specifications
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve.hydraulic self-adjusting lifters,2 valve per cylinder
Engine Capacity
984 cc / 60 cu in
Max Power
67.1 kw / 92 hp
Max Torque
97 Nm / 9.9 kgf-m / 71.5 ft.lbs @ 5500 rpm
Fuel Tank Capacity
3.7 US gallons / 14.0 L
Seat Height
30.5 inches / 775 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Buell XR9S Lightning
Year
2003
Engine
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve.hydraulic self-adjusting lifters,2 valve per cylinder
Displacement
984 cc / 60 cu in
Bore x Stroke
88.9 x 79.4 mm
Compression Ratio
10.0:1
Max Horsepower
67.1 kw / 92 hp
Max Torque
97 Nm / 9.9 kgf-m / 71.5 ft.lbs @ 5500 rpm
Engine Management System
45 mm Downdraft DDFI fuel injection
Lubrication System
Dry sump
Cooling System
Air cooled
Exhaust
Two-into-one, free breathing
Performance
Top Speed
210.2 km/h / 130.6 mph
*n/a – information not provided by manufacturer
Transmission
Clutch
Wet, multi-plate
Gearbox
5 Speed, constant mesh
Gear Ratios
1st2.69 / 2nd1.85 / 3rd1.43 / 4th1.18 / 5th1.00
Final Drive
Kevlar belt
Electrical & Electronics System
Battery
12V, 12Ah
Starter
Electric
Chassis & Suspension
Frame Type
Hollow aluminium twin-spar frame doubles as the fuel tank
Front Suspension
Showa upside-down forks, adjustable for preload, compression & rebound damping
Front Suspension Travel
4.7 inches / 119 mm
Rear Suspension
Showa shock absorber, adjustable for preload, compression & rebound damping
