The Buell XB12R Firebolt is a premium sportfighter motorcycle that embodies the perfect blend of American V-Twin muscle and track-inspired chassis dynamics.
Its compact wheelbase and race-inspired geometry make it incredibly nimble and intuitive to handle, allowing riders to carve through corners with confidence. The 1203cc Thunderstorm V-Twin engine delivers an impressive 103 peak horsepower at 6800 rpm, with a smooth and usable power delivery that’s perfect for both track days and canyon carving.
With its aerodynamic quarter-fairing, dual projector-beam headlamps, and sleek covered passenger pillion, the Firebolt XB12R is not only a thrill to ride but also a feast for the eyes. And with its reduced suggested retail price of $9,995, this motorcycle is now more accessible than ever to riders who crave an unrivaled riding experience.
The Buell XB12R Firebolt is a winner in every sense of the word – it’s been crowned “Best Cornering Motorcycle of All Time” by Britain’s Bike magazine and has taken multiple pro and amateur roadracing championships around the world.
Key Specifications
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve.hydraulic self-adjusting lifters,2 valve per cylinder.
Engine Capacity
1203 cc / 73 cu in
Max Power
86.9 kw / 103 hp
Max Torque
114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm
Fuel Tank Capacity
14 L / 3.7 US gal
Seat Height
775 mm / 30.5″
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Buell XB12R Firebolt
Year
2009
Engine
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve.hydraulic self-adjusting lifters,2 valve per cylinder.
Displacement
1203 cc / 73 cu in
Bore x Stroke
88.9 x 96.8 mm
Compression Ratio
10.0:1
Max Horsepower
86.9 kw / 103 hp
Max Torque
114 Nm / 11.6 kgf-m / 84 ft-lbs @ 6000 rpm
Engine Management System
49 mm downdraft DDFI II fuel injection
Cooling System
Air cooled
Exhaust
Free breathing, 2-into-1 Buell Interactive exhaust system
Performance
Top Speed
249 km/h / 155 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Frame Type
Aluminium frame with Uniplanar Powertrain vibration isolation system
Front Suspension
Showa 43 mm inverted forks compression damping, rebound damping and spring preload adjustable
Front Suspension Travel
120 mm / 4.7″
Rear Suspension
Showa coil-over monoshock, remote underseat reservoir and adjustable compression damping, rebound damping and spring preload, 127mm wheel travel
Rear Suspension Travel
127 mm / 5.0″
Rake
21
Trail
83 mm / 3.3″
Wheels & Brakes
Front Wheel/Rim Size
3.50 x 17″
Front Tire Size
120/70 ZR17, Pirelli Diablo
Rear Wheel/Rim Size
5.50 x 17″
Rear Tire Size
180/55 ZR17 Pirelli Diablo
Front Brakes
ZTL type brake, 6 piston, fixed caliper, 375 mm single-sided, inside out, stainless steel, floating rotor
Rear Brakes
Single 240 mm disc, 1 piston floating caliper
Dimension & Weights
Overall Length
1924 mm / 75.7″
Overall Width
768 mm / 30.2″
Overall Height
1092 mm / 43″
Seat Height
775 mm / 30.5″
Wheelbase
1320 mm / 52.0″
Ground Clearance
127 mm / 5.0″
Fuel Tank Capacity
14 L / 3.7 US gal
Dry Weight
179 kg / 395 lbs
Features
Compact wheelbase and race-inspired chassis geometry for nimble handling
1203cc Buell Thunderstorm V-Twin engine
103 peak horsepower at 6800 rpm
84 ft. lbs. of peak torque at 6000 rpm
75 percent of peak torque available at 3500 rpm
Buell InterActive Exhaust system with valve-controlled dual-chamber muffler
Adjustable exhaust flow according to riding conditions
ECM (Electronic Control Module) controlled engine management
Clip-on handlebars for optimal control
Aerodynamic quarter-fairing with dual projector-beam headlamps
Sleek, covered passenger pillion
Suggested retail price of $9,995
Redline increased to 7100 rpm on the Thunderstorm V-Twin powertrain
Pre-wired for accessory heated hand grips
Instrument panel styling refreshed
Tachometer reflects new 7100-rpm redline
Commemorative Buell 25th Anniversary graphic with Erik Buell’s signature
Cosmetic frame protectors for reduced damage in case of a tip-over
New color choice: Arctic White body panels, Hero Blue Translucid wheels and windscreen, and Graphite Grey frame
*We strive to provide the most comprehensive and accurate specifications possible. However, certain details may not be available if the manufacturer did not disclose them or if the information is no longer publicly accessible. If you find any discrepancy with any data on this site, please feel free to let us know at contact@throttlecraze.com
