The Buell S2T Thunderbolt embodies the perfect blend of performance and style. Powering this sleek machine is a 45-degree V-Twin engine, a descendant of Harley-Davidson’s iconic 1200 Sportster.
With its hydraulic self-adjusting lifters and 2 valves per cylinder, this engine delivers a robust 76 horsepower at 5,200 rpm, accompanied by an equally impressive 76 lb-ft of torque. The Thunderbolt’s riding position is a masterful compromise between the aggressive crouch of a racer and the relaxed slouch of a cruiser.
The bike’s advanced technology features are on full display, from its massive disc brake with 6-piston caliper to its inverted fork and subverted shock absorber. With an impressive curb weight of just 481 pounds, the Thunderbolt is ready to devour twisties and carve up corners with ease, making it a true thrill ride for any rider.
Key Specifications
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve,hydraulic self-adjusting lifters,2 valve per cylinder.
Engine Capacity
1203 cc / 73.4 cu in
Max Power
73.6 kw / 101 hp
Max Torque
90 Nm / 9.2 kgf-m / 66.4 lb.ft @ 5500 rpm
Fuel Tank Capacity
20.4 L / 5.4 US gal
Weight (Wet/Kerb)
481 lbs / 218 kg
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
Buell S2T Thunderbolt
Year
1994
Engine
Engine Type
45 V-Twin, four stroke, pushrod actuated overhead valve,hydraulic self-adjusting lifters,2 valve per cylinder.
Displacement
1203 cc / 73.4 cu in
Bore x Stroke
88.8 x 96.8 mm
Compression Ratio
10.0:1
Max Horsepower
73.6 kw / 101 hp
Max Torque
90 Nm / 9.2 kgf-m / 66.4 lb.ft @ 5500 rpm
Engine Management System
2 x 40 mm Keihin carburetors
Cooling System
Air cooled
Performance
Top Speed
201 km/h / 125 mph
*n/a – information not provided by manufacturer
Transmission
Gearbox
5 Speed
Final Drive
Kevlar belt
Electrical & Electronics System
Starter
Electric
Chassis & Suspension
Front Suspension
40 mm Showa fork, adjustable for compression and rebound damping
Front Suspension Travel
120 mm / 4.7″
Rear Suspension
Single Showa shock, spring preload, compression and preload damping
Rear Suspension Travel
116 mm / 4.6″
Wheels & Brakes
Front Tire Size
120/70 ZR17
Rear Tire Size
170/60 ZR17
Front Brakes
Single 340 mm disc, 6 piston caliper
Rear Brakes
Single 230 mm disc, 2 piston caliper
Dimension & Weights
Fuel Tank Capacity
20.4 L / 5.4 US gal
Wet (kerb/curb) Weight
481 lbs / 218 kg
Dry Weight
200 kg / 441 lbs
Features
45 V-Twin engine
Four stroke, pushrod actuated overhead valve design
Hydraulic self-adjusting lifters
2 valves per cylinder
76 horsepower at 5,200 rpm
Matching torque rating as horsepower
Huge disc brake with 6-piston caliper
Inverted fork
Subverted shock absorber
Carbon-fiber air cleaner cover
Oversize muffler for performance tuning
Curb weight of 481 pounds (218kg)
Production schedule of 300 units in debut year
S2T model introduced in 1996 with touring features
Color-coordinated saddlebags and fairing lowers on S2T
Touring handlebars and footpegs on S2T
