The BMW R68 is a marvel of motorcycle design, introduced in 1952 as the “100 mph motorcycle.” This road and cross-country variant boasts a robust engine, with a raised compression ratio of 7.7:1 and larger 26mm Bing carburetors, providing a potent punch for its time.
The R68’s engine character is unmistakable, with a rich, flat sound produced by its unique silencer system. The cross-country version’s single-fin silencer, with twin pipes crossing over the top of the engine, adds to its distinctive profile.
Riding the R68 is an exhilarating experience, with its telescopic front fork and plunger-type spring providing a smooth ride. The rear main bearing’s fully floating design allows for a hint of crankshaft flexibility, making it a joy to navigate twisties.
The BMW R68 is a testament to the brand’s commitment to innovation and performance, with a rich history that spans over five decades.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, pushrod operated 2 valves per cylinder.
Engine Capacity
594 cc / 36.2 cu in
Max Power
26.1 kw / 35 hp
Fuel Tank Capacity
17 liters /4.4 US gal
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 68
Year
1952 – 2054
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, pushrod operated 2 valves per cylinder.
Displacement
594 cc / 36.2 cu in
Bore x Stroke
72 x 73 mm
Compression Ratio
8.0:1
Max Horsepower
26.1 kw / 35 hp
Engine Management System
2 xBing 1/26/9 – 1/26/10 carburetors
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Single plate, dry
Gear Ratios
1st 4.00 2nd 2.28 3rd 1.7 4th 1.3
Electrical & Electronics System
Starter
Kick
Chassis & Suspension
Frame Type
Double loop steel tubular frame
Front Suspension
Telescopic front fork with hydraulic damping; plunger type
Rear Suspension
Spring with coil compression springs and rubber deflection stops
Wheels & Brakes
Front Tire Size
3.50 – 19″
Rear Tire Size
3.50 – 19″
Front Brakes
∅200mm Drum duplex full hub
Rear Brakes
∅200mm Drum simplex full hub
Dimension & Weights
Fuel Tank Capacity
17 liters /4.4 US gal
Features
Telescopic front fork with hydraulic damping
Plunger type Spring with coil compression springs and rubber deflection stops
7.7:1 compression ratio
26mm Bing carburetors
Fully floating rear main bearing
Reinforced crankshaft housing
35 HP power output at 7,000 rpm
Top speed of 100 mph (160 kph)
Additional ignition control on handlebars
Three degrees more advance with advance and retard bob-weights at rest than touring machines
Deeply valanced mudguards
Finned ring retained exhaust to the head
Upswept siamesed exhaust system on track version
Separate pillion pad on track version
Raised rear number-plate on track version
Larger exhaust pipe than touring machines
Torpedo silencers with slightly greater diameter
