The BMW R 60/2 is the latest iteration of the iconic R 60 model, which has been a staple of the BMW lineup for over a decade. Its roots in the world of sidecar racing are evident in its robust engine and smooth power delivery. This flat-twin engine is a masterclass in torque and reliability, making it an ideal companion for both solo riders and those who still appreciate the practicality of a sidecar.
The R 60/2’s engine character is a perfect blend of power and finesse, providing a smooth and linear power delivery that is both soothing and exhilarating. Its cooling system is designed to handle the rigors of heavy sidecar use, and its gearing is optimized for low-speed maneuverability.
Whether you’re navigating the twisties or cruising down the highway, the BMW R 60/2 is a joy to ride, its engine singing a soothing melody as you carve through the turns or cruise at high speed.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, pushrod operated 2 valves per cylinder.
Engine Capacity
594 cc / 36.2 cu in
Max Power
22.4 kw / 30 hp
Max Torque
49 Nm / 5.0 kgf-m / 36 ft lb @ 5000 rpm
Fuel Tank Capacity
17 L / 4.49 US gal
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 60/2
Year
1960 –
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer, pushrod operated 2 valves per cylinder.
Displacement
594 cc / 36.2 cu in
Bore x Stroke
72 x 73 mm
Compression Ratio
7.5:1
Max Horsepower
22.4 kw / 30 hp
Max Torque
49 Nm / 5.0 kgf-m / 36 ft lb @ 5000 rpm
Engine Management System
2 xType Bing 1/24/151 – 1/24/152
Cooling System
Air cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Single plate, saucer spring, dry
Gearbox
4 Speed
Gear Ratios
1st 4.17 / 2nd 2.73 / 3rd 1.94 / 4th 1.54:1
Final Drive
Shaft
Electrical & Electronics System
Starter
Kick
Chassis & Suspension
Front Suspension
Telescopic hydraulic forks
Rear Suspension
Long swinging arm with strut
Wheels & Brakes
Front Tire Size
3.50 – S18
Rear Tire Size
3.50 – S18
Front Brakes
200mm Drum
Rear Brakes
200mm Drum
Dimension & Weights
Fuel Tank Capacity
17 L / 4.49 US gal
Features
BMW sidecar model R60
Low center of gravity
Heavy flywheel
Smooth engine output
Even firing pulses
Balanced reciprocating masses
Horizontally-opposed powerplant
Good engine braking
High torque
Reliable, mildly tuned engine
Good cooling characteristics
Low gearing
Pronounced flywheel effect
Smooth power delivery
Low engine height
Carburetion that doesn’t lean out under horizontal g-loads
Low wind resistance
Stability
Low weight (for a sidecar rig)
