The BMW R 18 B is a masterclass in American-style touring and cruising, delivering a potent blend of power, elegance, and customization possibilities.
At its heart lies the mighty 1802cc Big Boxer engine, a horizontally opposed two-cylinder powerhouse that exudes raw emotion and unbridled performance. With four valves per cylinder and pushrod-actuated OHV with two camshafts, this is an engine that truly comes alive on the open road.
The R 18 B’s sleek, low-slung stance and fork-mounted fairing create a sense of drama and purpose, while its low windshield and slimmer seat invite riders to immerse themselves in the ride. Whether carving through twisties or cruising down the highway, this bike is all about delivering an unforgettable experience that will leave you grinning from ear to ear – and begging for more time behind the handlebars.
Key Specifications
Engine Type
Four stroke, two cylinder horizontally opposed Boxer,Pushrod-actuated OHVwith two camshafts, 4 valves per cylinder
Engine Capacity
110 cubic inches / 1802 cc
Max Power
67 kw / 91 hp
Max Torque
116 ft-lb / 158 nm
Fuel Tank Capacity
6.3 US gallons / 24.0 L
Weight (Wet/Kerb)
877 lbs / 398 kg
Seat Height
28.35 inches / 720 mm
*n/a – information not provided by manufacturer
All Specifications
Make & Model
Model
BMW R 18 B
Year
2022
Engine
Engine Type
Four stroke, two cylinder horizontally opposed Boxer,Pushrod-actuated OHVwith two camshafts, 4 valves per cylinder
Displacement
110 cubic inches / 1802 cc
Bore x Stroke
107.1 X 100 mm
Compression Ratio
9.6:1
Max Horsepower
67 kw / 91 hp
Max Torque
116 ft-lb / 158 nm
Lubrication System
Wet sump
Cooling System
Air/water cooled
Performance
Top Speed
n/a
*n/a – information not provided by manufacturer
Transmission
Clutch
Hydraulically activated single-disc dry clutch
Gearbox
6-speed shifting claw transmission in separate transmission housing
Final Drive
Shaft
Electrical & Electronics System
Battery
12 V /26 Ah, maintenance-free
Starter
Electric, 1.5 kW
ABS
BMW Motorrad Integral ABS (part-integral)
Chassis & Suspension
Frame Type
Double-cradle steel frame
Front Suspension
49 mm Telescopic fork, Non-adjustable
Front Suspension Travel
4.7 inches / 120 mm
Rear Suspension
Steel double-sided swinging arm with central spring strut
Rear Suspension Travel
4.7 inches / 120 mm
Trail
62.7
Wheels & Brakes
Wheels
Cast aluminium
Front Wheel/Rim Size
3.5 x 19
Front Tire Size
120/70 R19
Rear Wheel/Rim Size
5.0 x 16
Rear Tire Size
180/65 B16
Front Brakes
2x 300mm discs, 4-piston fixed caliper
Rear Brakes
Single 300mm disc, 4-piston fixed caliper
ABS
BMW Motorrad Integral ABS (part-integral)
Dimension & Weights
Overall Length
2560 mm / 100.8 in
Overall Width
970 mm / 38.2 in
Overall Height
1400 mm / 55.1 in
Seat Height
28.35 inches / 720 mm
Wheelbase
66.7 inches / 1695 mm
Fuel Tank Capacity
6.3 US gallons / 24.0 L
Wet (kerb/curb) Weight
877 lbs / 398 kg
Features
Four stroke, two cylinder horizontally opposed Boxer engine
Pushrod-actuated OHV with two camshafts
4 valves per cylinder
Closed-loop 3-way catalytic converter
EURO 5 exhaust standard
Steel double-sided swinging arm with central spring strut
1802 cc Big Boxer engine
Output of 67 kW (91 hp) at 4750 rpm
Over 150 Nm of torque in the 2000 to 4000 rpm range
Double-loop tube frame made of steel
Backbone made of sheet metal formed parts
Rear swinging arm with enclosed axle drive
Front fairing with high wind shield, wind deflector and flaps (R 18 Transcontinental)
Cockpit with four analogue round instruments and 10.25 inch TFT colour display (R 18 Transcontinental)
Additional headlamp (R 18 Transcontinental)
Marshall sound system (R 18 Transcontinental)
Engine protection bars (R 18 Transcontinental)
Cases (R 18 Transcontinental)
Top case (R 18 Transcontinental)
Seat heating (R 18 Transcontinental)
Chrome trim (R 18 Transcontinental)
Matt black metallic engine (R 18 B)
