BMW R 1200ST (2007)

BMW R 1200ST (2007)

The BMW R 1200 ST is a high-performance touring machine that embodies the perfect blend of comfort and sportiness. Its four-stroke, two-cylinder Boxer engine produces a smooth and potent 108 horsepower, with a distinctive exhaust note that’s both music to the ears and a testament to its mechanical prowess.

The R 1200 ST’s rakish bodywork is a masterclass in aerodynamics, with twin stacked headlights that cut through the darkness and a pointed lower fairing that channels cooling air to the engine and oil cooler. The mechanically adjustable windscreen allows riders to tailor the amount of wind protection to their liking, while the sporty ergonomics and adjustable clip-on handlebars provide maximum control and comfort for high-speed touring.

Whether carving through twisties or cruising down the highway, the R 1200 ST is a thrilling ride that’s equally at home on long-distance tours or spirited canyon runs. Its comfortable and sporty riding position, coupled with its impressive performance and advanced technology, makes it the ultimate touring motorcycle for riders who crave excitement and adventure.

Key Specifications

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Engine Capacity1170 cc / 71.4 cu in
Max Power81 kw / 110 hp
Max Torque115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm
Fuel Tank Capacity21 Liters / 5.5 US gal
Seat Height32.5 inches / 826 mm
BMW R 1200ST (2007)

All Specifications

Make & Model

ModelBMW R 1200ST
Year2007

Engine

Engine TypeFour stroke, two cylinder horizontally opposed Boxer, 4 valves per cylinder
Displacement1170 cc / 71.4 cu in
Bore x Stroke101 x 73 mm
Compression Ratio11.0:1
Max Horsepower81 kw / 110 hp
Max Torque115 Nm / 11.7 kgf-m / 85 lb-ft @ 6000 rpm
Engine Management SystemBMW engine management, BMS-K
Cooling SystemAir/Oil-cooled

Performance

Top Speed233.6 km/h / 145 mph

Transmission

ClutchSingle dry plate clutch, hydraulically
Gearbox6 Speed
Gear Ratios1st 2.28 / 2nd 1.58 / 3rd 1.26 / 4th 1.03 / 5th 0.90 / 6th 0.81:1
Final DriveSystem enclosed driveshaft with two universal joints

Electrical & Electronics System

Battery12 V / 14 Ah, maintenance-free
StarterElectric

Chassis & Suspension

Frame TypeThree-sectionframeconsistingoffrontandrearsection,loadbearingengine-gearboxunit
Front SuspensionThree-section frame consisting of front and rear section, load bearing engine-gearbox unit
Front Suspension Travel4.3 inches / 110 mm
Rear SuspensionBMW Motorrad Telelever, stanchion diameter 35mm, central spring strut, rebound damping electronically adjustable with standard ESA
Rear Suspension Travel5.5 inches / 140 mm
Trail64.3

Wheels & Brakes

WheelsCast aluminium
Front Tire Size120/70 ZR17
Rear Tire Size180/55 ZR17
Front Brakes2 x 305 mm Discs, 4 piston calipers
Rear BrakesSingle 265mm disc, 2 piston caliper

Dimension & Weights

Seat Height32.5 inches / 826 mm
Wheelbase59.1 inches / 1495 mm
Fuel Tank Capacity21 Liters / 5.5 US gal
Dry Weight205 kg / 451.9 lbs

Features

  • Four stroke, two cylinder horizontally opposed Boxer engine
  • 4 valves per cylinder
  • Three-section frame with load-bearing engine-gearbox unit
  • 780 mm / 800 mm seat height (low seat bench)
  • Twin stacked headlights
  • Mechanically adjustable windscreen
  • Adjustable clip-on handlebars
  • Ergonomic stance for maximum control and comfort
  • Adjustable alloy handlebars (vertically adjustable 1 inch / 25mm)
  • Dual-position adjustable rider’s saddle (31.9 or 32.7 inches / 810 or 830mm)
  • Optional lower saddle (30.7 or 31.5 inches / 780 or 800mm)
  • Info Flatscreen rider-information display
  • Oil temperature, fuel consumption, and tank level information
  • Gear selection display
  • 110 hp maximum power
  • 12.0:1 compression ratio
  • Revised camshafts for greater thermal efficiency and increased airflow
  • High-cam activation system with single, lightweight camshaft
