BMW R 1200S Endurance Racer (2007)

BMW R 1200S Endurance Racer (2007)

The BMW R 1200S Endurance Racer embodies the perfect blend of power, agility, and endurance, making it the closest thing to a Superbike BMW has ever built. At the heart of this beast lies a four-stroke, two-cylinder horizontally opposed Boxer engine, pumping out 140bhp and 4 valves per cylinder.

The air/oil-cooled powerplant is perfectly suited to the demands of endurance racing, providing a smooth and predictable power delivery that’s a joy to ride. With a fully-fuelled weight of just 195kg, this machine is a force to be reckoned with on the track.

The BMW R 1200S Endurance Racer is the ultimate test of man and machine, pushed to its limits by some of the world’s top road racers, including Stphane Mertens, Thomas Hinterreiter, and Rico Penzkofer, who collectively demonstrated its incredible capabilities in the grueling LeMans 24-hour endurance race.

Key Specifications

Engine TypeFour stroke, two cylinder horizontally opposed Boxer air/oil-cooled, 4 valves per cylinder
Engine Capacity1170
Max Power130 hp 96 kW @ 9500 rpm
Fuel Tank Capacity23 Litres
BMW R 1200S Endurance Racer (2007)

All Specifications

Make & Model

ModelBMW R 1200S Endurance Racer
Year2007

Engine

Engine TypeFour stroke, two cylinder horizontally opposed Boxer air/oil-cooled, 4 valves per cylinder
Displacement1170
Bore x Stroke101 x 73 mm
Max Horsepower130 hp 96 kW @ 9500 rpm
Engine Management SystemFuel injection, 52mm throttle butterfly

Performance

Top Speedn/a

Transmission

ClutchSingle dry plate clutch, 180 mm
Gearbox6 Speed
Gear Ratios1st 2.277 / 2nd 1.583 / 3rd 1.259 / 4th 1.033 / 5th 1.903 / 6th 1.805
Final DriveShaft

Electrical & Electronics System

StarterElectric

Chassis & Suspension

Frame TypeMain and front frame made of steel tubing, rear section omitted, partially self-supporting powertrain
Front SuspensionBMW Telelever with hlins suspension strut, 110 wheel travel
Rear SuspensionBMW Paralever with hlins suspension strut, 120 wheel travel

Wheels & Brakes

Front Tire Size120/70 ZR 17
Rear Tire Size195/55 ZR 17
Front Brakes2x 305mm discs 4 piston caliper
Rear BrakesSingle 265mm disc

Dimension & Weights

Fuel Tank Capacity23 Litres

Features

  • 4-stroke engine
  • 2-cylinder horizontally opposed Boxer configuration
  • Air/oil-cooled
  • 4 valves per cylinder
  • 140bhp
  • 195kg fully-fuelled weight
  • Based on R1200S model
  • Entry into LeMans 24-hour endurance race in 2007
